:WMEMory<r> Commands 31
Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide 763
:WMEMory<r>:LABel
(see page 860)
Command Syntax
:WMEMory<r>:LABel <string>
<r> ::= 1-2 in NR1 format
<string> ::= quoted ASCII string
The :WMEMory<r>:LABel command sets the reference waveform label to
the string that follows.
Setting a label for a reference waveform also adds the name to the label
list in non- volatile memory (replacing the oldest label in the list).
Query Syntax
:WMEMory<r>:LABel?
The :WMEMory<r>:LABel? query returns the label associated with a
particular reference waveform.
Return Format
<string><NL>
<string> ::= quoted ASCII string
See Also • Chapter 31, “:WMEMory<r> Commands,” starting on page 759
• ":WMEMory<r>:DISPlay" on page 762
NOTE
Label strings are 10 characters or less, and may contain any commonly used ASCII
characters. Labels with more than 10 characters are truncated to 10 characters. Lower case
characters are converted to upper case.
