746 Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide
30 :WGEN Commands
:WGEN:FUNCtion
(see page 860)
Command Syntax
:WGEN:FUNCtion <signal>
<signal> ::= {SINusoid | SQUare | RAMP | PULSe | NOISe | DC}
The :WGEN:FUNCtion command selects the type of waveform:
Waveform
Type
Characteristics
SINusoid Use these commands to set the sine signal parameters:
• ":WGEN:FREQuency" on page 745
• ":WGEN:PERiod" on page 753
• ":WGEN:VOLTage" on page 755
• ":WGEN:VOLTage:OFFSet" on page 758
• ":WGEN:VOLTage:HIGH" on page 756
• ":WGEN:VOLTage:LOW" on page 757
The frequency can be adjusted from 100 mHz to 20 MHz.
SQUare Use these commands to set the square wave signal parameters:
• ":WGEN:FREQuency" on page 745
• ":WGEN:PERiod" on page 753
• ":WGEN:VOLTage" on page 755
• ":WGEN:VOLTage:OFFSet" on page 758
• ":WGEN:VOLTage:HIGH" on page 756
• ":WGEN:VOLTage:LOW" on page 757
• ":WGEN:FUNCtion:SQUare:DCYCle" on page 750
The frequency can be adjusted from 100 mHz to 10 MHz.
The duty cycle can be adjusted from 20% to 80%.
RAMP Use these commands to set the ramp signal parameters:
• ":WGEN:FREQuency" on page 745
• ":WGEN:PERiod" on page 753
• ":WGEN:VOLTage" on page 755
• ":WGEN:VOLTage:OFFSet" on page 758
• ":WGEN:VOLTage:HIGH" on page 756
• ":WGEN:VOLTage:LOW" on page 757
• ":WGEN:FUNCtion:RAMP:SYMMetry" on page 749
The frequency can be adjusted from 100 mHz to 100 kHz.
Symmetry represents the amount of time per cycle that the ramp waveform is
rising and can be adjusted from 0% to 100%.
