744 Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide
30 :WGEN Commands
Introduction to
:WGEN
Commands
The :WGEN subsystem provides commands to select the waveform
generator function and parameters.
Reporting the Setup
Use :WGEN? to query setup information for the WGEN subsystem.
Return Format
The following is a sample response from the :WGEN? query. In this case,
the query was issued following the *RST command.
:WGEN:FUNC SIN;OUTP 0;FREQ +1.0000E+03;VOLT +500.0E-03;VOLT:OFFS
+0.0E+00;:WGEN:OUTP:LOAD ONEM
:WGEN:VOLTage
<amplitude> (see
page 755)
:WGEN:VOLTage? (see
page 755)
<amplitude> ::= amplitude in
volts in NR3 format
:WGEN:VOLTage:HIGH
<high> (see page 756)
:WGEN:VOLTage:HIGH?
(see page 756)
<high> ::= high-level voltage in
volts, in NR3 format
:WGEN:VOLTage:LOW
<low> (see page 757)
:WGEN:VOLTage:LOW?
(see page 757)
<low> ::= low-level voltage in
volts, in NR3 format
:WGEN:VOLTage:OFFSet
<offset> (see
page 758)
:WGEN:VOLTage:OFFSet?
(see page 758)
<offset> ::= offset in volts in
NR3 format
Table 116 :WGEN Commands Summary (continued)
Command Query Options and Query Returns
