734 Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide
29 :WAVeform Commands
:WAVeform:TYPE
(see page 860)
Query Syntax
:WAVeform:TYPE?
The :WAVeform:TYPE? query returns the acquisition mode associated with
the currently selected waveform. The acquisition mode is set by the
:ACQuire:TYPE command.
Return Format
<mode><NL>
<mode> ::= {NORM | PEAK | AVER | HRES}
See Also • "Introduction to :WAVeform Commands" on page 709
• ":ACQuire:TYPE" on page 199
• ":WAVeform:DATA" on page 717
• ":WAVeform:PREamble" on page 724
• ":WAVeform:SOURce" on page 729
NOTE
If the :WAVeform:SOURce is POD1, POD2, or SBUS1, SBUS2, the type is always NORM.
