728 Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide
29 :WAVeform Commands
:WAVeform:SEGMented:TTAG
(see page 860)
Query Syntax
:WAVeform:SEGMented:TTAG?
The :WAVeform:SEGMented:TTAG? query returns the time tag of the
currently selected segmented memory index. The index is selected using
the :ACQuire:SEGMented:INDex command.
Return Format
<time_tag> ::= in NR3 format
See Also • ":ACQuire:SEGMented:INDex" on page 195
• "Introduction to :WAVeform Commands" on page 709
Example Code • "Example Code" on page 195
NOTE
This command is available when the segmented memory option (Option SGM) is enabled.
