72 Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide
4 Commands Quick Reference
Table 12 :FUNCtion Commands Summary
Command Query Options and Query Returns
:FUNCtion:CENTer
<frequency> (see
page 272)
:FUNCtion:CENTer?
(see page 272)
<frequency> ::= the current
center frequency in NR3 format.
The range of legal values is from
0 Hz to 25 GHz.
:FUNCtion:DISPlay {{0
| OFF} | {1 | ON}}
(see page 273)
:FUNCtion:DISPlay?
(see page 273)
{0 | 1}
:FUNCtion:GOFT:OPERat
ion <operation> (see
page 274)
:FUNCtion:GOFT:OPERat
ion? (see page 274)
<operation> ::= {ADD | SUBTract |
MULTiply}
:FUNCtion:GOFT:SOURce
1 <source> (see
page 275)
:FUNCtion:GOFT:SOURce
1? (see page 275)
<source> ::= CHANnel<n>
<n> ::= {1 | 2 | 3 | 4} for 4ch
models
<n> ::= {1 | 2} for 2ch models
:FUNCtion:GOFT:SOURce
2 <source> (see
page 276)
:FUNCtion:GOFT:SOURce
2? (see page 276)
<source> ::= CHANnel<n>
<n> ::= {{1 | 2} | {3 | 4}} for
4ch models, depending on SOURce1
selection
<n> ::= {1 | 2} for 2ch models
:FUNCtion:OFFSet
<offset> (see
page 277)
:FUNCtion:OFFSet?
(see page 277)
<offset> ::= the value at center
screen in NR3 format.
The range of legal values is
+/-10 times the current
sensitivity of the selected
function.
:FUNCtion:OPERation
<operation> (see
page 278)
:FUNCtion:OPERation?
(see page 278)
<operation> ::= {ADD | SUBTract |
MULTiply | INTegrate | DIFF | FFT
| SQRT}
:FUNCtion:RANGe
<range> (see
page 279)
:FUNCtion:RANGe? (see
page 279)
<range> ::= the full-scale
vertical axis value in NR3
format.
The range for ADD, SUBT, MULT is
8E-6 to 800E+3. The range for the
INTegrate function is 8E-9 to
400E+3.
The range for the DIFF function
is 80E-3 to 8.0E12 (depends on
current sweep speed).
The range for the FFT function is
8 to 800 dBV.
