ManualsBrandsAgilent Technologies ManualsPower ToolsInfiniiVision 3000 DSO-X 3054A

Table Of Contents

In This Book
Contents
What's New
- What's New in Version 1.10
- Version 1.00 at Introduction
- Command Differences From 7000B Series Oscilloscopes
Setting Up
- Step 1. Install Agilent IO Libraries Suite software
- Step 2. Connect and set up the oscilloscope
- Step 3. Verify the oscilloscope connection
Getting Started
- Basic Oscilloscope Program Structure
- Programming the Oscilloscope
- Other Ways of Sending Commands
  - Telnet Sockets
  - Sending SCPI Commands Using Browser Web Control
Commands Quick Reference
- Command Summary
- Syntax Elements
Common (*) Commands
- *CLS (Clear Status)
- *ESE (Standard Event Status Enable)
- *ESR (Standard Event Status Register)
- *IDN (Identification Number)
- *LRN (Learn Device Setup)
- *OPC (Operation Complete)
- *OPT (Option Identification)
- *RCL (Recall)
- *RST (Reset)
- *SAV (Save)
- *SRE (Service Request Enable)
- *STB (Read Status Byte)
- *TRG (Trigger)
- *TST (Self Test)
- *WAI (Wait To Continue)
Root (:) Commands
- :ACTivity
- :AER (Arm Event Register)
- :AUToscale
- :AUToscale:AMODE
- :AUToscale:CHANnels
- :AUToscale:FDEBug
- :BLANk
- :DIGitize
- :MTEenable (Mask Test Event Enable Register)
- :MTERegister[:EVENt] (Mask Test Event Event Register)
- :OPEE (Operation Status Enable Register)
- :OPERegister:CONDition (Operation Status Condition Register)
- :OPERegister[:EVENt] (Operation Status Event Register)
- :OVLenable (Overload Event Enable Register)
- :OVLRegister (Overload Event Register)
- :PRINt
- :RUN
- :SERial
- :SINGle
- :STATus
- :STOP
- :TER (Trigger Event Register)
- :VIEW
:ACQuire Commands
- :ACQuire:COMPlete
- :ACQuire:COUNt
- :ACQuire:MODE
- :ACQuire:POINts
- :ACQuire:SEGMented:ANALyze
- :ACQuire:SEGMented:COUNt
- :ACQuire:SEGMented:INDex
- :ACQuire:SRATe
- :ACQuire:TYPE
:BUS Commands
- :BUS:BIT
- :BUS:BITS
- :BUS:CLEar
- :BUS:DISPlay
- :BUS:LABel
- :BUS:MASK
:CALibrate Commands
- :CALibrate:DATE
- :CALibrate:LABel
- :CALibrate:OUTPut
- :CALibrate:PROTected
- :CALibrate:STARt
- :CALibrate:STATus
- :CALibrate:TEMPerature
- :CALibrate:TIME
:CHANnel Commands
- :CHANnel:BWLimit
- :CHANnel:COUPling
- :CHANnel:DISPlay
- :CHANnel:IMPedance
- :CHANnel:INVert
- :CHANnel:LABel
- :CHANnel:OFFSet
- :CHANnel:PROBe
- :CHANnel:PROBe:HEAD[:TYPE]
- :CHANnel:PROBe:ID
- :CHANnel:PROBe:SKEW
- :CHANnel:PROBe:STYPe
- :CHANnel:PROTection
- :CHANnel:RANGe
- :CHANnel:SCALe
- :CHANnel:UNITs
- :CHANnel:VERNier
:DEMO Commands
- :DEMO:FUNCtion
- :DEMO:FUNCtion:PHASe:PHASe
- :DEMO:OUTPut
:DIGital Commands
- :DIGital:DISPlay
- :DIGital:LABel
- :DIGital:POSition
- :DIGital:SIZE
- :DIGital:THReshold
:DISPlay Commands
- :DISPlay:CLEar
- :DISPlay:DATA
- :DISPlay:LABel
- :DISPlay:LABList
- :DISPlay:PERSistence
- :DISPlay:VECTors
:EXTernal Trigger Commands
- :EXTernal:BWLimit
- :EXTernal:PROBe
- :EXTernal:RANGe
- :EXTernal:UNITs
:FUNCtion Commands
- :FUNCtion:CENTer
- :FUNCtion:DISPlay
- :FUNCtion:GOFT:OPERation
- :FUNCtion:GOFT:SOURce1
- :FUNCtion:GOFT:SOURce2
- :FUNCtion:OFFSet
- :FUNCtion:OPERation
- :FUNCtion:RANGe
- :FUNCtion:REFerence
- :FUNCtion:SCALe
- :FUNCtion:SOURce1
- :FUNCtion:SOURce2
- :FUNCtion:SPAN
- :FUNCtion:WINDow
:HARDcopy Commands
- :HARDcopy:AREA
- :HARDcopy:APRinter
- :HARDcopy:FACTors
- :HARDcopy:FFEed
- :HARDcopy:INKSaver
- :HARDcopy:LAYout
- :HARDcopy:NETWork:ADDRess
- :HARDcopy:NETWork:APPLy
- :HARDcopy:NETWork:DOMain
- :HARDcopy:NETWork:PASSword
- :HARDcopy:NETWork:SLOT
- :HARDcopy:NETWork:USERname
- :HARDcopy:PALette
- :HARDcopy:PRINter:LIST
- :HARDcopy:STARt
:LISTer Commands
- :LISTer:DATA
- :LISTer:DISPlay
- :LISTer:REFerence
:MARKer Commands
- :MARKer:MODE
- :MARKer:X1Position
- :MARKer:X1Y1source
- :MARKer:X2Position
- :MARKer:X2Y2source
- :MARKer:XDELta
- :MARKer:Y1Position
- :MARKer:Y2Position
- :MARKer:YDELta
:MEASure Commands
- :MEASure:ALL
- :MEASure:AREa
- :MEASure:BWIDth
- :MEASure:CLEar
- :MEASure:COUNter
- :MEASure:DEFine
- :MEASure:DELay
- :MEASure:DUTYcycle
- :MEASure:FALLtime
- :MEASure:FREQuency
- :MEASure:NEDGes
- :MEASure:NPULses
- :MEASure:NWIDth
- :MEASure:OVERshoot
- :MEASure:PEDGes
- :MEASure:PERiod
- :MEASure:PHASe
- :MEASure:PPULses
- :MEASure:PREShoot
- :MEASure:PWIDth
- :MEASure:RESults
- :MEASure:RISetime
- :MEASure:SDEViation
- :MEASure:SHOW
- :MEASure:SOURce
- :MEASure:STATistics
- :MEASure:STATistics:INCRement
- :MEASure:STATistics:RESet
- :MEASure:TEDGe
- :MEASure:TVALue
- :MEASure:VAMPlitude
- :MEASure:VAVerage
- :MEASure:VBASe
- :MEASure:VMAX
- :MEASure:VMIN
- :MEASure:VPP
- :MEASure:VRATio
- :MEASure:VRMS
- :MEASure:VTIMe
- :MEASure:VTOP
- :MEASure:WINDow
- :MEASure:XMAX
- :MEASure:XMIN
:MTESt Commands
- :MTESt:ALL
- :MTESt:AMASk:CREate
- :MTESt:AMASk:SOURce
- :MTESt:AMASk:UNITs
- :MTESt:AMASk:XDELta
- :MTESt:AMASk:YDELta
- :MTESt:COUNt:FWAVeforms
- :MTESt:COUNt:RESet
- :MTESt:COUNt:TIME
- :MTESt:COUNt:WAVeforms
- :MTESt:DATA
- :MTESt:DELete
- :MTESt:ENABle
- :MTESt:LOCK
- :MTESt:RMODe
- :MTESt:RMODe:FACTion:MEASure
- :MTESt:RMODe:FACTion:PRINt
- :MTESt:RMODe:FACTion:SAVE
- :MTESt:RMODe:FACTion:STOP
- :MTESt:RMODe:SIGMa
- :MTESt:RMODe:TIME
- :MTESt:RMODe:WAVeforms
- :MTESt:SCALe:BIND
- :MTESt:SCALe:X1
- :MTESt:SCALe:XDELta
- :MTESt:SCALe:Y1
- :MTESt:SCALe:Y2
- :MTESt:SOURce
- :MTESt:TITLe
:POD Commands
- :POD:DISPlay
- :POD:SIZE
- :POD:THReshold
:RECall Commands
- :RECall:FILename
- :RECall:MASK[:STARt]
- :RECall:PWD
- :RECall:SETup[:STARt]
- :RECall:WMEMory[:STARt]
:SAVE Commands
- :SAVE:FILename
- :SAVE:IMAGe[:STARt]
- :SAVE:IMAGe:FACTors
- :SAVE:IMAGe:FORMat
- :SAVE:IMAGe:INKSaver
- :SAVE:IMAGe:PALette
- :SAVE:LISTer[:STARt]
- :SAVE:MASK[:STARt]
- :SAVE:PWD
- :SAVE:SETup[:STARt]
- :SAVE:WAVeform[:STARt]
- :SAVE:WAVeform:FORMat
- :SAVE:WAVeform:LENGth
- :SAVE:WAVeform:SEGMented
- :SAVE:WMEMory:SOURce
- :SAVE:WMEMory[:STARt]
:SBUS Commands
- General :SBUS Commands
  - :SBUS:DISPlay
  - :SBUS:MODE
- :SBUS:CAN Commands
- :SBUS:I2S Commands
- :SBUS:IIC Commands
- :SBUS:LIN Commands
- :SBUS:SPI Commands
- :SBUS:UART Commands
:SEARch Commands
- General :SEARch Commands
- :SEARch:EDGE Commands
  - :SEARch:EDGE:SLOPe
  - :SEARch:EDGE:SOURce
- :SEARch:GLITch Commands
- :SEARch:RUNT Commands
- :SEARch:TRANsition Commands
- :SEARch:SERial:CAN Commands
- :SEARch:SERial:I2S Commands
- :SEARch:SERial:IIC Commands
- :SEARch:SERial:LIN Commands
- :SEARch:SERial:SPI Commands
- :SEARch:SERial:UART Commands
:SYSTem Commands
- :SYSTem:DATE
- :SYSTem:DSP
- :SYSTem:ERRor
- :SYSTem:LOCK
- :SYSTem:PRESet
- :SYSTem:PROTection:LOCK
- :SYSTem:SETup
- :SYSTem:TIME
:TIMebase Commands
- :TIMebase:MODE
- :TIMebase:POSition
- :TIMebase:RANGe
- :TIMebase:REFerence
- :TIMebase:SCALe
- :TIMebase:VERNier
- :TIMebase:WINDow:POSition
- :TIMebase:WINDow:RANGe
- :TIMebase:WINDow:SCALe
:TRIGger Commands
- General :TRIGger Commands
- :TRIGger:EBURst Commands
- :TRIGger[:EDGE] Commands
- :TRIGger:GLITch Commands
- :TRIGger:PATTern Commands
- :TRIGger:RUNT Commands
- :TRIGger:SHOLd Commands
- :TRIGger:TRANsition Commands
- :TRIGger:TV Commands
- :TRIGger:USB Commands
:WAVeform Commands
- :WAVeform:BYTeorder
- :WAVeform:COUNt
- :WAVeform:DATA
- :WAVeform:FORMat
- :WAVeform:POINts
- :WAVeform:POINts:MODE
- :WAVeform:PREamble
- :WAVeform:SEGMented:COUNt
- :WAVeform:SEGMented:TTAG
- :WAVeform:SOURce
- :WAVeform:SOURce:SUBSource
- :WAVeform:TYPE
- :WAVeform:UNSigned
- :WAVeform:VIEW
- :WAVeform:XINCrement
- :WAVeform:XORigin
- :WAVeform:XREFerence
- :WAVeform:YINCrement
- :WAVeform:YORigin
- :WAVeform:YREFerence
:WGEN Commands
- :WGEN:FREQuency
- :WGEN:FUNCtion
- :WGEN:FUNCtion:PULSe:WIDTh
- :WGEN:FUNCtion:RAMP:SYMMetry
- :WGEN:FUNCtion:SQUare:DCYCle
- :WGEN:OUTPut
- :WGEN:OUTPut:LOAD
- :WGEN:PERiod
- :WGEN:RST
- :WGEN:VOLTage
- :WGEN:VOLTage:HIGH
- :WGEN:VOLTage:LOW
- :WGEN:VOLTage:OFFSet
:WMEMory Commands
- :WMEMory:CLEar
- :WMEMory:DISPlay
- :WMEMory:LABel
- :WMEMory:SAVE
- :WMEMory:SKEW
- :WMEMory:YOFFset
- :WMEMory:YRANge
- :WMEMory:YSCale
Obsolete and Discontinued Commands
- :CHANnel:ACTivity
- :CHANnel:LABel
- :CHANnel:THReshold
- :CHANnel2:SKEW
- :CHANnel:INPut
- :CHANnel:PMODe
- :DISPlay:CONNect
- :DISPlay:ORDer
- :ERASe
- :EXTernal:PMODe
- :FUNCtion:SOURce
- :FUNCtion:VIEW
- :HARDcopy:DESTination
- :HARDcopy:FILename
- :HARDcopy:GRAYscale
- :HARDcopy:IGColors
- :HARDcopy:PDRiver
- :MEASure:LOWer
- :MEASure:SCRatch
- :MEASure:TDELta
- :MEASure:THResholds
- :MEASure:TMAX
- :MEASure:TMIN
- :MEASure:TSTArt
- :MEASure:TSTOp
- :MEASure:TVOLt
- :MEASure:UPPer
- :MEASure:VDELta
- :MEASure:VSTArt
- :MEASure:VSTOp
- :MTESt:AMASk:{SAVE | STORe}
- :MTESt:AVERage
- :MTESt:AVERage:COUNt
- :MTESt:LOAD
- :MTESt:RUMode
- :MTESt:RUMode:SOFailure
- :MTESt:{STARt | STOP}
- :MTESt:TRIGger:SOURce
- :PRINt?
- :SAVE:IMAGe:AREA
- :SBUS:LIN:SIGNal:DEFinition
- :TIMebase:DELay
- :TRIGger:THReshold
- :TRIGger:TV:TVMode
Error Messages
Status Reporting
- Status Reporting Data Structures
- Status Byte Register (STB)
- Service Request Enable Register (SRE)
- Trigger Event Register (TER)
- Output Queue
- Message Queue
- (Standard) Event Status Register (ESR)
- (Standard) Event Status Enable Register (ESE)
- Error Queue
- Operation Status Event Register (:OPERegister[:EVENt])
- Operation Status Condition Register (:OPERegister:CONDition)
- Arm Event Register (AER)
- Overload Event Register (:OVLRegister)
- Mask Test Event Event Register (:MTERegister[:EVENt])
- Clearing Registers and Queues
- Status Reporting Decision Chart
Synchronizing Acquisitions
- Synchronization in the Programming Flow
- Blocking Synchronization
- Polling Synchronization With Timeout
- Synchronizing with a Single-Shot Device Under Test (DUT)
- Synchronization with an Averaging Acquisition
More About Oscilloscope Commands
- Command Classifications
- Valid Command/Query Strings
- Query Return Values
- All Oscilloscope Commands Are Sequential
Programming Examples
- VISA COM Examples
- VISA Examples
- SICL Examples
  - SICL Example in C
  - SICL Example in Visual Basic
Index

Commands Quick Reference 4

Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide 71

Table 10 :DISPlay Commands Summary

Command Query Options and Query Returns

:DISPlay:CLEar (see

page 257)

n/a n/a

n/a :DISPlay:DATA?

[<format>][,][<palett

e>] (see page 258)

<format> ::= {BMP | BMP8bit |

PNG}

<palette> ::= {COLor | GRAYscale}

<display data> ::= data in IEEE

488.2 # format

:DISPlay:LABel {{0 |

OFF} | {1 | ON}} (see

page 259)

:DISPlay:LABel? (see

page 259)

{0 | 1}

:DISPlay:LABList

<binary block> (see

page 260)

:DISPlay:LABList?

(see page 260)

<binary block> ::= an ordered

list of up to 75 labels, each 10

characters maximum, separated by

newline characters

:DISPlay:PERSistence

<value> (see

page 261)

:DISPlay:PERSistence?

(see page 261)

<value> ::= {MINimum | INFinite |

<time>}

<time> ::= seconds in in NR3

format from 100E-3 to 60E0

:DISPlay:VECTors {1 |

ON} (see page 262)

:DISPlay:VECTors?

(see page 262)

Table 11 :EXTernal Trigger Commands Summary

Command Query Options and Query Returns

:EXTernal:BWLimit

<bwlimit> (see

page 264)

:EXTernal:BWLimit?

(see page 264)

<bwlimit> ::= {0 | OFF}

:EXTernal:PROBe

<attenuation> (see

page 265)

:EXTernal:PROBe? (see

page 265)

<attenuation> ::= probe

attenuation ratio in NR3 format

:EXTernal:RANGe

<range>[<suffix>]

(see page 266)

:EXTernal:RANGe? (see

page 266)

<range> ::= vertical full-scale

range value in NR3 format

<suffix> ::= {V | mV}

:EXTernal:UNITs

<units> (see

page 267)

:EXTernal:UNITs? (see

page 267)

<units> ::= {VOLT | AMPere}
