696 Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide
28 :TRIGger Commands
:TRIGger:TV Commands
Table 112 :TRIGger:TV Commands Summary
Command Query Options and Query Returns
:TRIGger:TV:LINE
<line number> (see
page 697)
:TRIGger:TV:LINE?
(see page 697)
<line number> ::= integer in NR1
format
:TRIGger:TV:MODE <tv
mode> (see page 698)
:TRIGger:TV:MODE?
(see page 698)
<tv mode> ::= {FIEld1 | FIEld2 |
AFIelds | ALINes | LFIeld1 |
LFIeld2 | LALTernate}
:TRIGger:TV:POLarity
<polarity> (see
page 699)
:TRIGger:TV:POLarity?
(see page 699)
<polarity> ::= {POSitive |
NEGative}
:TRIGger:TV:SOURce
<source> (see
page 700)
:TRIGger:TV:SOURce?
(see page 700)
<source> ::= {CHANnel<n>}
<n> ::= 1 to (# analog channels)
in NR1 format
:TRIGger:TV:STANdard
<standard> (see
page 701)
:TRIGger:TV:STANdard?
(see page 701)
<standard> ::= {NTSC | PAL | PALM
| SECam}
