:TRIGger Commands 28
Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide 691
:TRIGger:TRANsition Commands
The :TRIGger:TRANsition comamnds set the rise/fall time trigger options.
Table 111 :TRIGger:TRANsition Commands Summary
Command Query Options and Query Returns
:TRIGger:TRANsition:Q
UALifier <qualifier>
(see page 692)
:TRIGger:TRANsition:Q
UALifier? (see
page 692)
<qualifier> ::= {GREaterthan |
LESSthan}
:TRIGger:TRANsition:S
LOPe <slope> (see
page 693)
:TRIGger:TRANsition:S
LOPe? (see page 693)
<slope> ::= {NEGative | POSitive}
:TRIGger:TRANsition:S
OURce <source> (see
page 694)
:TRIGger:TRANsition:S
OURce? (see page 694)
<source> ::= CHANnel<n>
<n> ::= 1 to (# analog channels)
in NR1 format
:TRIGger:TRANsition:T
IME <time>[suffix]
(see page 695)
:TRIGger:TRANsition:T
IME? (see page 695)
<time> ::= floating-point number
in NR3 format
[suffix] ::= {s | ms | us | ns |
ps}
