68 Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide
4 Commands Quick Reference
n/a :CALibrate:STATus?
(see page 218)
<return value> ::=
<status_code>,<status_string>
<status_code> ::= an integer
status code
<status_string> ::= an ASCII
status string
n/a :CALibrate:TEMPeratur
e? (see page 219)
<return value> ::= degrees C
delta since last cal in NR3
format
n/a :CALibrate:TIME? (see
page 220)
<return value> ::=
<hours>,<minutes>,<seconds>; all
in NR1 format
Table 6 :CALibrate Commands Summary (continued)
Command Query Options and Query Returns
Table 7 :CHANnel<n> Commands Summary
Command Query Options and Query Returns
:CHANnel<n>:BWLimit
{{0 | OFF} | {1 |
ON}} (see page 224)
:CHANnel<n>:BWLimit?
(see page 224)
{0 | 1}
<n> ::= 1 to (# analog channels)
in NR1 format
:CHANnel<n>:COUPling
<coupling> (see
page 225)
:CHANnel<n>:COUPling?
(see page 225)
<coupling> ::= {AC | DC}
<n> ::= 1 to (# analog channels)
in NR1 format
:CHANnel<n>:DISPlay
{{0 | OFF} | {1 |
ON}} (see page 226)
:CHANnel<n>:DISPlay?
(see page 226)
{0 | 1}
<n> ::= 1 to (# analog channels)
in NR1 format
:CHANnel<n>:IMPedance
<impedance> (see
page 227)
:CHANnel<n>:IMPedance
? (see page 227)
<impedance> ::= {ONEMeg | FIFTy}
<n> ::= 1 to (# analog channels)
in NR1 format
:CHANnel<n>:INVert
{{0 | OFF} | {1 |
ON}} (see page 228)
:CHANnel<n>:INVert?
(see page 228)
{0 | 1}
<n> ::= 1 to (# analog channels)
in NR1 format
:CHANnel<n>:LABel
<string> (see
page 229)
:CHANnel<n>:LABel?
(see page 229)
<string> ::= any series of 10 or
less ASCII characters enclosed in
quotation marks
<n> ::= 1 to (# analog channels)
in NR1 format
:CHANnel<n>:OFFSet
<offset>[suffix] (see
page 230)
:CHANnel<n>:OFFSet?
(see page 230)
<offset> ::= Vertical offset
value in NR3 format
[suffix] ::= {V | mV}
<n> ::= 1-2 or 1-4; in NR1 format
