66 Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide
4 Commands Quick Reference
Table 4 :ACQuire Commands Summary
Command Query Options and Query Returns
:ACQuire:COMPlete
<complete> (see
page 189)
:ACQuire:COMPlete?
(see page 189)
<complete> ::= 100; an integer in
NR1 format
:ACQuire:COUNt
<count> (see
page 190)
:ACQuire:COUNt? (see
page 190)
<count> ::= an integer from 2 to
65536 in NR1 format
:ACQuire:MODE <mode>
(see page 191)
:ACQuire:MODE? (see
page 191)
<mode> ::= {RTIMe | SEGMented}
n/a :ACQuire:POINts? (see
page 192)
<# points> ::= an integer in NR1
format
:ACQuire:SEGMented:AN
ALyze (see page 193)
n/a n/a (with Option SGM)
:ACQuire:SEGMented:CO
UNt <count> (see
page 194)
:ACQuire:SEGMented:CO
UNt? (see page 194)
<count> ::= an integer from 2 to
1000 in NR1 format (with Option
SGM)
:ACQuire:SEGMented:IN
Dex <index> (see
page 195)
:ACQuire:SEGMented:IN
Dex? (see page 195)
<index> ::= an integer from 1 to
1000 in NR1 format (with Option
SGM)
n/a :ACQuire:SRATe? (see
page 198)
<sample_rate> ::= sample rate
(samples/s) in NR3 format
:ACQuire:TYPE <type>
(see page 199)
:ACQuire:TYPE? (see
page 199)
<type> ::= {NORMal | AVERage |
HRESolution | PEAK}
Table 5 :BUS<n> Commands Summary
Command Query Options and Query Returns
:BUS<n>:BIT<m> {{0 |
OFF} | {1 | ON}} (see
page 203)
:BUS<n>:BIT<m>? (see
page 203)
{0 | 1}
<n> ::= 1 or 2; an integer in NR1
format
<m> ::= 0-15; an integer in NR1
format
:BUS<n>:BITS
<channel_list>, {{0 |
OFF} | {1 | ON}} (see
page 204)
:BUS<n>:BITS? (see
page 204)
<channel_list>, {0 | 1}
<channel_list> ::= (@<m>,<m>:<m>
...) where "," is separator and
":" is range
<n> ::= 1 or 2; an integer in NR1
format
<m> ::= 0-15; an integer in NR1
format
