:SEARch Commands 25
Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide 601
:SEARch:SERial:LIN Commands
Table 99 :SEARch:SERial:LIN Commands Summary
Command Query Options and Query Returns
:SEARch:SERial:LIN:ID
<value> (see
page 602)
:SEARch:SERial:LIN:ID
? (see page 602)
<value> ::= 7-bit integer in
decimal, <nondecimal>, or
<string> from 0-63 or 0x00-0x3f
(with Option AMS)
<nondecimal> ::= #Hnn where n ::=
{0,..,9 | A,..,F} for hexadecimal
<nondecimal> ::= #Bnn...n where n
::= {0 | 1} for binary
<string> ::= "0xnn" where n ::=
{0,..,9 | A,..,F} for hexadecimal
:SEARch:SERial:LIN:MO
DE <value> (see
page 603)
:SEARch:SERial:LIN:MO
DE? (see page 603)
<value> ::= {ID | DATA | ERRor}
:SEARch:SERial:LIN:PA
TTern:DATA <string>
(see page 604)
:SEARch:SERial:LIN:PA
TTern:DATA? (see
page 604)
<string> ::= "n" where n ::=
32-bit integer in signed decimal
when <base> = DECimal
<string> ::= "0xnn...n" where n
::= {0,..,9 | A,..,F | X } when
<base> = HEX
:SEARch:SERial:LIN:PA
TTern:DATA:LENGth
<length> (see
page 605)
:SEARch:SERial:LIN:PA
TTern:DATA:LENGth?
(see page 605)
<length> ::= integer from 1 to 8
in NR1 format
:SEARch:SERial:LIN:PA
TTern:FORMat <base>
(see page 606)
:SEARch:SERial:LIN:PA
TTern:FORMat? (see
page 606)
<base> ::= {HEX | DECimal}
