572 Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide
25 :SEARch Commands
:SEARch:RUNT Commands
Table 94 :SEARch:RUNT Commands Summary
Command Query Options and Query Returns
:SEARch:RUNT:POLarity
<polarity> (see
page 573)
:SEARch:RUNT:POLarity
? (see page 573)
<polarity> ::= {POSitive |
NEGative | EITHer}
:SEARch:RUNT:QUALifie
r <qualifier> (see
page 574)
:SEARch:RUNT:QUALifie
r? (see page 574)
<qualifier> ::= {GREaterthan |
LESSthan | NONE}
:SEARch:RUNT:SOURce
<source> (see
page 575)
:SEARch:RUNT:SOURce?
(see page 575)
<source> ::= CHANnel<n>
<n> ::= 1 to (# analog channels)
in NR1 format
:SEARch:RUNT:TIME
<time>[suffix] (see
page 576)
:SEARch:RUNT:TIME?
(see page 576)
<time> ::= floating-point number
in NR3 format
[suffix] ::= {s | ms | us | ns |
ps}
