518 Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide
24 :SBUS<n> Commands
:SBUS<n>:SPI Commands
NOTE
These commands are only valid when the low-speed IIC and SPI serial decode option
(Option LSS) has been licensed.
Table 89 :SBUS<n>:SPI Commands Summary
Command Query Options and Query Returns
:SBUS<n>:SPI:BITorder
<order> (see
page 520)
:SBUS<n>:SPI:BITorder
? (see page 520)
<order> ::= {LSBFirst | MSBFirst}
:SBUS<n>:SPI:CLOCk:SL
OPe <slope> (see
page 521)
:SBUS<n>:SPI:CLOCk:SL
OPe? (see page 521)
<slope> ::= {NEGative | POSitive}
:SBUS<n>:SPI:CLOCk:TI
Meout <time_value>
(see page 522)
:SBUS<n>:SPI:CLOCk:TI
Meout? (see page 522)
<time_value> ::= time in seconds
in NR3 format
:SBUS<n>:SPI:FRAMing
<value> (see
page 523)
:SBUS<n>:SPI:FRAMing?
(see page 523)
<value> ::= {CHIPselect |
{NCHipselect | NOTC} | TIMeout}
:SBUS<n>:SPI:SOURce:C
LOCk <source> (see
page 524)
:SBUS<n>:SPI:SOURce:C
LOCk? (see page 524)
<value> ::= {CHANnel<n> |
EXTernal} for the DSO models
<value> ::= {CHANnel<n> |
DIGital<d>} for the MSO models
<n> ::= 1 to (# analog channels)
in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
:SBUS<n>:SPI:SOURce:D
ATA <source> (see
page 525)
:SBUS<n>:SPI:SOURce:D
ATA? (see page 525)
<value> ::= {CHANnel<n> |
EXTernal} for the DSO models
<value> ::= {CHANnel<n> |
DIGital<d>} for the MSO models
<n> ::= 1 to (# analog channels)
in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
:SBUS<n>:SPI:SOURce:F
RAMe <source> (see
page 526)
:SBUS<n>:SPI:SOURce:F
RAMe? (see page 526)
<value> ::= {CHANnel<n> |
EXTernal} for the DSO models
<value> ::= {CHANnel<n> |
DIGital<d>} for the MSO models
<n> ::= 1 to (# analog channels)
in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
