:SBUS<n> Commands 24
Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide 457
:SBUS<n>:MODE
(see page 860)
Command Syntax
:SBUS<n>:MODE <mode>
<mode> ::= {CAN | I2S | IIC | LIN | SPI | UART}
The :SBUS<n>:MODE command determines the decode mode for the serial
bus.
Query Syntax
:SBUS<n>:MODE?
The :SBUS<n>:MODE? query returns the current serial bus decode mode
setting.
Return Format
<mode><NL>
<mode> ::= {CAN | I2S | IIC | LIN | SPI | UART | NONE}
Errors "- 241, Hardware missing" on page 823
See Also "Introduction to :SBUS<n> Commands" on page 453
":SBUS<n>:CAN Commands" on page 458
":SBUS<n>:I2S Commands" on page 475
":SBUS<n>:IIC Commands" on page 494
":SBUS<n>:LIN Commands" on page 504
":SBUS<n>:SPI Commands" on page 518
":SBUS<n>:UART Commands" on page 535
NOTE
This command is only valid when a serial decode option has been licensed.
