:RECall Commands 22
Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide 427
:RECall:FILename
(see page 860)
Command Syntax
:RECall:FILename <base_name>
<base_name> ::= quoted ASCII string
The :RECall:FILename command specifies the source for any RECall
operations.
Query Syntax
:RECall:FILename?
The :RECall:FILename? query returns the current RECall filename.
Return Format
<base_name><NL>
<base_name> ::= quoted ASCII string
See Also • "Introduction to :RECall Commands" on page 425
• ":RECall:SETup[:STARt]" on page 430
• ":SAVE:FILename" on page 436
NOTE
This command specifies a file's base name only, without path information or an extension.
