:RECall Commands
Recall previously saved oscilloscope setups, reference waveforms, and
masks.
Introduction to
:RECall
Commands
The :RECall subsystem provides commands to recall previously saved
oscilloscope setups, reference waveforms, and masks.
Reporting the Setup
Use :RECall? to query setup information for the RECall subsystem.
Table 82 :RECall Commands Summary
Command Query Options and Query Returns
:RECall:FILename
<base_name> (see
page 427)
:RECall:FILename?
(see page 427)
<base_name> ::= quoted ASCII
string
:RECall:MASK[:STARt]
[<file_spec>] (see
page 428)
n/a <file_spec> ::= {<internal_loc>
| <file_name>}
<internal_loc> ::= 0-3; an
integer in NR1 format
<file_name> ::= quoted ASCII
string
:RECall:PWD
<path_name> (see
page 429)
:RECall:PWD? (see
page 429)
<path_name> ::= quoted ASCII
string
:RECall:SETup[:STARt]
[<file_spec>] (see
page 430)
n/a <file_spec> ::= {<internal_loc>
| <file_name>}
<internal_loc> ::= 0-9; an
integer in NR1 format
<file_name> ::= quoted ASCII
string
:RECall:WMEMory<r>[:S
TARt] [<file_name>]
(see page 431)
n/a <r> ::= 1-2 in NR1 format
<file_name> ::= quoted ASCII
string
If extension included in file
name, it must be ".h5".
