386 Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide
20 :MTESt Commands
:MTESt:DELete (see
page 401)
n/a n/a
:MTESt:ENABle {{0 |
OFF} | {1 | ON}} (see
page 402)
:MTESt:ENABle? (see
page 402)
{0 | 1}
:MTESt:LOCK {{0 |
OFF} | {1 | ON}} (see
page 403)
:MTESt:LOCK? (see
page 403)
{0 | 1}
:MTESt:RMODe <rmode>
(see page 404)
:MTESt:RMODe? (see
page 404)
<rmode> ::= {FORever | TIME |
SIGMa | WAVeforms}
:MTESt:RMODe:FACTion:
MEASure {{0 | OFF} |
{1 | ON}} (see
page 405)
:MTESt:RMODe:FACTion:
MEASure? (see
page 405)
{0 | 1}
:MTESt:RMODe:FACTion:
PRINt {{0 | OFF} | {1
| ON}} (see page 406)
:MTESt:RMODe:FACTion:
PRINt? (see page 406)
{0 | 1}
:MTESt:RMODe:FACTion:
SAVE {{0 | OFF} | {1
| ON}} (see page 407)
:MTESt:RMODe:FACTion:
SAVE? (see page 407)
{0 | 1}
:MTESt:RMODe:FACTion:
STOP {{0 | OFF} | {1
| ON}} (see page 408)
:MTESt:RMODe:FACTion:
STOP? (see page 408)
{0 | 1}
:MTESt:RMODe:SIGMa
<level> (see
page 409)
:MTESt:RMODe:SIGMa?
(see page 409)
<level> ::= from 0.1 to 9.3 in
NR3 format
:MTESt:RMODe:TIME
<seconds> (see
page 410)
:MTESt:RMODe:TIME?
(see page 410)
<seconds> ::= from 1 to 86400 in
NR3 format
:MTESt:RMODe:WAVeform
s <count> (see
page 411)
:MTESt:RMODe:WAVeform
s? (see page 411)
<count> ::= number of waveforms
in NR1 format
:MTESt:SCALe:BIND {{0
| OFF} | {1 | ON}}
(see page 412)
:MTESt:SCALe:BIND?
(see page 412)
{0 | 1}
:MTESt:SCALe:X1
<x1_value> (see
page 413)
:MTESt:SCALe:X1? (see
page 413)
<x1_value> ::= X1 value in NR3
format
Table 80 :MTESt Commands Summary (continued)
Command Query Options and Query Returns
