334 Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide
19 :MEASure Commands
:MEASure:BWIDth
(see page 860)
Command Syntax
:MEASure:BWIDth [<source>]
<source> ::= {CHANnel<n> | FUNCtion | MATH | WMEMory<r>}
<n> ::= 1 to (# analog channels) in NR1 format
<r> ::= 1-2 in NR1 format
The :MEASure:BWIDth command installs a burst width measurement on
screen. If the optional source parameter is not specified, the current
measurement source is used.
Query Syntax
:MEASure:BWIDth? [<source>]
The :MEASure:BWIDth? query measures and returns the width of the burst
on the screen.
The burst width is calculated as follows:
burst width = (last edge on screen - first edge on screen)
Return Format
<value><NL>
<value> ::= burst width in seconds in NR3 format
See Also • "Introduction to :MEASure Commands" on page 330
• ":MEASure:SOURce" on page 362
NOTE
This command is not available if the source is FFT (Fast Fourier Transform).
