:MEASure Commands 19
Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide 323
:MEASure:FALLtime
[<source>] (see
page 343)
:MEASure:FALLtime?
[<source>] (see
page 343)
<source> ::= {CHANnel<n> |
FUNCtion | MATH | WMEMory<r>} for
DSO models
<source> ::= {CHANnel<n> |
DIGital<d> | FUNCtion | MATH |
WMEMory<r>} for MSO models
<n> ::= 1 to (# analog channels)
in NR1 format
<r> ::= 1-2 in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
<return_value> ::= time in
seconds between the lower and
upper thresholds in NR3 format
:MEASure:FREQuency
[<source>] (see
page 344)
:MEASure:FREQuency?
[<source>] (see
page 344)
<source> ::= {CHANnel<n> |
FUNCtion | MATH | WMEMory<r>} for
DSO models
<source> ::= {CHANnel<n> |
DIGital<d> | FUNCtion | MATH |
WMEMory<r>} for MSO models
<n> ::= 1 to (# analog channels)
in NR1 format
<r> ::= 1-2 in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
<return_value> ::= frequency in
Hertz in NR3 format
:MEASure:NEDGes
[<source>] (see
page 345)
:MEASure:NEDGes?
[<source>] (see
page 345)
<source> ::= {CHANnel<n> |
FUNCtion | MATH | WMEMory<r>}
<n> ::= 1 to (# analog channels)
in NR1 format
<r> ::= 1-2 in NR1 format
<return_value> ::= the falling
edge count in NR3 format
:MEASure:NPULses
[<source>] (see
page 346)
:MEASure:NPULses?
[<source>] (see
page 346)
<source> ::= {CHANnel<n> |
FUNCtion | MATH | WMEMory<r>}
<n> ::= 1 to (# analog channels)
in NR1 format
<r> ::= 1-2 in NR1 format
<return_value> ::= the falling
pulse count in NR3 format
Table 79 :MEASure Commands Summary (continued)
Command Query Options and Query Returns
