260 Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide
13 :DISPlay Commands
:DISPlay:LABList
(see page 860)
Command Syntax
:DISPlay:LABList <binary block data>
<binary block> ::= an ordered list of up to 75 labels, a maximum of 10
characters each, separated by newline characters.
The :DISPlay:LABList command adds labels to the label list. Labels are
added in alphabetical order.
Query Syntax
:DISPlay:LABList?
The :DISPlay:LABList? query returns the label list.
Return Format
<binary block><NL>
<binary block> ::= an ordered list of up to 75 labels, a maximum of 10
characters each, separated by newline characters.
See Also • "Introduction to :DISPlay Commands" on page 255
• ":DISPlay:LABel" on page 259
• ":CHANnel<n>:LABel" on page 229
• ":DIGital<d>:LABel" on page 250
• ":BUS<n>:LABel" on page 208
NOTE
Labels that begin with the same alphabetic base string followed by decimal digits are
considered duplicate labels. Duplicate labels are not added to the label list. For example, if
label "A0" is in the list and you try to add a new label called "A123456789", the new label is
not added.
