:DIGital<d> Commands 12
Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide 251
:DIGital<d>:POSition
(see page 860)
Command Syntax
:DIGital<d>:POSition <position>
<d> ::= 0 to (# digital channels - 1) in NR1 format
<position> ::= integer in NR1 format.
The :DIGital<d>:POSition command sets the position of the specified
channel.
Query Syntax
:DIGital<d>:POSition?
The :DIGital<d>:POSition? query returns the position of the specified
channel.
If the returned value is "- 1", this indicates there is no space to display the
digital waveform (for example, when all serial lanes, digital buses, and the
zoomed time base are displayed).
Return Format
<position><NL>
<position> ::= integer in NR1 format.
See Also "Introduction to :DIGital<d> Commands" on page 247
Channel Size Position Top Bottom
Large 0-7 7 0
Medium 0-15 15 0
Small 0-31 31 0
NOTE
This command is only valid for the MSO models.
