:CHANnel<n> Commands 10
Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide 227
:CHANnel<n>:IMPedance
(see page 860)
Command Syntax
:CHANnel<n>:IMPedance <impedance>
<impedance> ::= {ONEMeg | FIFTy}
<n> ::= 1 to (# analog channels) in NR1 format
The :CHANnel<n>:IMPedance command selects the input impedance setting
for the specified analog channel. The legal values for this command are
ONEMeg (1 M
) and FIFTy (50).
Query Syntax
:CHANnel<n>:IMPedance?
The :CHANnel<n>:IMPedance? query returns the current input impedance
setting for the specified channel.
Return Format
<impedance value><NL>
<impedance value> ::= {ONEM | FIFT}
See Also • "Introduction to :CHANnel<n> Commands" on page 222
NOTE
The analog channel input impedance of the 100 MHz bandwidth oscilloscope models is
fixed at ONEMeg (1 M
).
