:CALibrate Commands 9
Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide 215
:CALibrate:OUTPut
(see page 860)
Command Syntax
:CALibrate:OUTPut <signal>
<signal> ::= {TRIGgers | MASK | WAVEgen}
The CALibrate:OUTPut command sets the signal that is available on the
rear panel TRIG OUT BNC:
• TRIGgers — pulse when a trigger event occurs.
• MASK — signal from mask test indicating a failure.
• WAVEgen — waveform generator sync output signal. This signal depends
on the :WGEN:FUNCtion setting:
The Sync signal is a TTL "high" when the waveform's output is positive,
relative to zero volts (or the DC offset value). The Sync signal is a TTL
"low" when the output is negative, relative to zero volts (or the DC
offset value).
Query Syntax
:CALibrate:OUTPut?
The :CALibrate:OUTPut query returns the current source of the TRIG OUT
BNC signal.
Return Format
<signal><NL>
<signal> ::= {TRIG | MASK | WAVE}
See Also • "Introduction to :CALibrate Commands" on page 211
• ":WGEN:FUNCtion" on page 746
Waveform
Type
Sync Signal Characteristics
SINusoid,
RAMP,
PULSe
The Sync signal is a square waveform with a 50% duty cycle.
SQUare The Sync signal is a square waveform with the same duty cycle as the main
output.
DC N/A
NOISe N/A
