206 Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide
8 :BUS<n> Commands
:BUS<n>:CLEar
(see page 860)
Command Syntax
:BUS<n>:CLEar
<n> ::= An integer, 1 or 2, is attached as a suffix to BUS
and defines the bus that is affected by the command.
The :BUS<n>:CLEar command excludes all of the digital channels from the
selected bus definition.
See Also • "Introduction to :BUS<n> Commands" on page 202
• ":BUS<n>:BIT<m>" on page 203
• ":BUS<n>:BITS" on page 204
• ":BUS<n>:DISPlay" on page 207
• ":BUS<n>:LABel" on page 208
• ":BUS<n>:MASK" on page 209
NOTE
This command is only valid for the MSO models.
