Agilent InfiniiVision 3000 X-Series Oscilloscopes
Programmer's Guide
7
:ACQuire Commands
Set the parameters for acquiring and storing data. See "Introduction to
:ACQuire Commands" on page 187.
Introduction to
:ACQuire
Commands
The ACQuire subsystem controls the way in which waveforms are
acquired. These acquisition types are available: normal, averaging, peak
detect, and high resolution.
Normal
Table 67 :ACQuire Commands Summary
Command Query Options and Query Returns
:ACQuire:COMPlete
<complete> (see
page 189)
:ACQuire:COMPlete?
(see page 189)
<complete> ::= 100; an integer in
NR1 format
:ACQuire:COUNt
<count> (see
page 190)
:ACQuire:COUNt? (see
page 190)
<count> ::= an integer from 2 to
65536 in NR1 format
:ACQuire:MODE <mode>
(see page 191)
:ACQuire:MODE? (see
page 191)
<mode> ::= {RTIMe | SEGMented}
n/a :ACQuire:POINts? (see
page 192)
<# points> ::= an integer in NR1
format
:ACQuire:SEGMented:AN
ALyze (see page 193)
n/a n/a (with Option SGM)
:ACQuire:SEGMented:CO
UNt <count> (see
page 194)
:ACQuire:SEGMented:CO
UNt? (see page 194)
<count> ::= an integer from 2 to
1000 in NR1 format (with Option
SGM)
:ACQuire:SEGMented:IN
Dex <index> (see
page 195)
:ACQuire:SEGMented:IN
Dex? (see page 195)
<index> ::= an integer from 1 to
1000 in NR1 format (with Option
SGM)
n/a :ACQuire:SRATe? (see
page 198)
<sample_rate> ::= sample rate
(samples/s) in NR3 format
:ACQuire:TYPE <type>
(see page 199)
:ACQuire:TYPE? (see
page 199)
<type> ::= {NORMal | AVERage |
HRESolution | PEAK}
