Root (:) Commands 6
Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide 183
:STATus
(see page 860)
Query Syntax
:STATus? <source>
<source> ::= {CHANnel<n> | FUNCtion | MATH | SBUS{1 | 2}}
for the DSO models
<source> ::= {CHANnel<n> | DIGital<d> | POD{1 | 2}
| BUS{1 | 2} | FUNCtion | MATH | SBUS{1 | 2}}
for the MSO models
<n> ::= 1 to (# analog channels) in NR1 format
<d> ::= 0 to (# digital channels - 1) in NR1 format
The :STATus? query reports whether the channel, function, or serial
decode bus specified by <source> is displayed.
Return Format
<value><NL>
<value> ::= {1 | 0}
See Also • "Introduction to Root (:) Commands" on page 154
• ":BLANk" on page 162
• ":CHANnel<n>:DISPlay" on page 226
• ":DIGital<d>:DISPlay" on page 249
• ":FUNCtion:DISPlay" on page 273
• ":POD<n>:DISPlay" on page 421
• ":VIEW" on page 186
NOTE
MATH is an alias for FUNCtion.
