6 Root (:) Commands
:BLANk
(see page 860)
Command Syntax
:BLANk [<source>]
<source> ::= {CHANnel<n> | FUNCtion | MATH | SBUS{1 | 2}}
for the DSO models
<source> ::= {CHANnel<n> | DIGital<d> | POD{1 | 2}
| BUS{1 | 2} | FUNCtion | MATH | SBUS{1 | 2}}
for the MSO models
<n> ::= 1 to (# analog channels) in NR1 format
<d> ::= 0 to (# digital channels - 1) in NR1 format
The :BLANk command turns off (stops displaying) the specified channel,
digital pod, math function, or serial decode bus. The :BLANk command
with no parameter turns off all sources.
See Also • "Introduction to Root (:) Commands" on page 154
• ":DISPlay:CLEar" on page 257
• ":CHANnel<n>:DISPlay" on page 226
• ":DIGital<d>:DISPlay" on page 249
• ":FUNCtion:DISPlay" on page 273
• ":POD<n>:DISPlay" on page 421
• ":STATus" on page 183
• ":VIEW" on page 186
Example Code • "Example Code" on page 186
NOTE
To turn on (start displaying) a channel, etc., use the :VIEW command. The DISPlay
commands, :CHANnel<n>:DISPlay, :FUNCtion:DISPlay, :POD<n>:DISPlay, or
:DIGital<n>:DISPlay, are the preferred method to turn on/off a channel, etc.
NOTE
MATH is an alias for FUNCtion.
