120 Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide
4 Commands Quick Reference
:WMEMory<r>:SKEW
<skew> (see page 765)
:WMEMory<r>:SKEW?
(see page 765)
<r> ::= 1-2 in NR1 format
<skew> ::= time in seconds in NR3
format
:WMEMory<r>:YOFFset
<offset>[suffix] (see
page 766)
:WMEMory<r>:YOFFset?
(see page 766)
<r> ::= 1-2 in NR1 format
<offset> ::= vertical offset
value in NR3 format
[suffix] ::= {V | mV}
:WMEMory<r>:YRANge
<range>[suffix] (see
page 767)
:WMEMory<r>:YRANge?
(see page 767)
<r> ::= 1-2 in NR1 format
<range> ::= vertical full-scale
range value in NR3 format
[suffix] ::= {V | mV}
:WMEMory<r>:YSCale
<scale>[suffix] (see
page 768)
:WMEMory<r>:YSCale?
(see page 768)
<r> ::= 1-2 in NR1 format
<scale> ::= vertical units per
division value in NR3 format
[suffix] ::= {V | mV}
Table 53 :WMEMory<r> Commands Summary (continued)
Command Query Options and Query Returns
