Commands Quick Reference 4
Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide 119
:WGEN:OUTPut:LOAD
<impedance> (see
page 752)
:WGEN:OUTPut:LOAD?
(see page 752)
<impedance> ::= {ONEMeg | FIFTy}
:WGEN:PERiod <period>
(see page 753)
:WGEN:PERiod? (see
page 753)
<period> ::= period in seconds in
NR3 format
:WGEN:RST (see
page 754)
n/a n/a
:WGEN:VOLTage
<amplitude> (see
page 755)
:WGEN:VOLTage? (see
page 755)
<amplitude> ::= amplitude in
volts in NR3 format
:WGEN:VOLTage:HIGH
<high> (see page 756)
:WGEN:VOLTage:HIGH?
(see page 756)
<high> ::= high-level voltage in
volts, in NR3 format
:WGEN:VOLTage:LOW
<low> (see page 757)
:WGEN:VOLTage:LOW?
(see page 757)
<low> ::= low-level voltage in
volts, in NR3 format
:WGEN:VOLTage:OFFSet
<offset> (see
page 758)
:WGEN:VOLTage:OFFSet?
(see page 758)
<offset> ::= offset in volts in
NR3 format
Table 52 :WGEN Commands Summary (continued)
Command Query Options and Query Returns
Table 53 :WMEMory<r> Commands Summary
Command Query Options and Query Returns
:WMEMory<r>:CLEar
(see page 761)
n/a <r> ::= 1-2 in NR1 format
:WMEMory<r>:DISPlay
{{0 | OFF} | {1 |
ON}} (see page 762)
:WMEMory<r>:DISPlay?
(see page 762)
<r> ::= 1-2 in NR1 format
{0 | 1}
:WMEMory<r>:LABel
<string> (see
page 763)
:WMEMory<r>:LABel?
(see page 763)
<r> ::= 1-2 in NR1 format
<string> ::= any series of 10 or
less ASCII characters enclosed in
quotation marks
:WMEMory<r>:SAVE
<source> (see
page 764)
n/a <r> ::= 1-2 in NR1 format
<source> ::= {CHANnel<n> |
FUNCtion | MATH}
<n> ::= 1 to (# analog channels)
in NR1 format
NOTE: Only ADD or SUBtract math
operations can be saved as
reference waveforms.
