118 Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide
4 Commands Quick Reference
n/a :WAVeform:XINCrement?
(see page 737)
<return_value> ::= x-increment
in the current preamble in NR3
format
n/a :WAVeform:XORigin?
(see page 738)
<return_value> ::= x-origin
value in the current preamble in
NR3 format
n/a :WAVeform:XREFerence?
(see page 739)
<return_value> ::= 0
(x-reference value in the current
preamble in NR1 format)
n/a :WAVeform:YINCrement?
(see page 740)
<return_value> ::= y-increment
value in the current preamble in
NR3 format
n/a :WAVeform:YORigin?
(see page 741)
<return_value> ::= y-origin in
the current preamble in NR3
format
n/a :WAVeform:YREFerence?
(see page 742)
<return_value> ::= y-reference
value in the current preamble in
NR1 format
Table 51 :WAVeform Commands Summary (continued)
Command Query Options and Query Returns
Table 52 :WGEN Commands Summary
Command Query Options and Query Returns
:WGEN:FREQuency
<frequency> (see
page 745)
:WGEN:FREQuency? (see
page 745)
<frequency> ::= frequency in Hz
in NR3 format
:WGEN:FUNCtion
<signal> (see
page 746)
:WGEN:FUNCtion? (see
page 747)
<signal> ::= {SINusoid | SQUare |
RAMP | PULSe | NOISe | DC}
:WGEN:FUNCtion:PULSe:
WIDTh <width> (see
page 748)
:WGEN:FUNCtion:PULSe:
WIDTh? (see page 748)
<width> ::= pulse width in
seconds in NR3 format
:WGEN:FUNCtion:RAMP:S
YMMetry <percent>
(see page 749)
:WGEN:FUNCtion:RAMP:S
YMMetry? (see
page 749)
<percent> ::= symmetry
percentage from 0% to 100% in NR3
format
:WGEN:FUNCtion:SQUare
:DCYCle <percent>
(see page 750)
:WGEN:FUNCtion:SQUare
:DCYCle? (see
page 750)
<percent> ::= duty cycle
percentage from 20% to 80% in NR3
format
:WGEN:OUTPut {{0 |
OFF} | {1 | ON}} (see
page 751)
:WGEN:OUTPut? (see
page 751)
{0 | 1}
