Commands Quick Reference 4
Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide 115
Table 49 :TRIGger:TV Commands Summary
Command Query Options and Query Returns
:TRIGger:TV:LINE
<line number> (see
page 697)
:TRIGger:TV:LINE?
(see page 697)
<line number> ::= integer in NR1
format
:TRIGger:TV:MODE <tv
mode> (see page 698)
:TRIGger:TV:MODE?
(see page 698)
<tv mode> ::= {FIEld1 | FIEld2 |
AFIelds | ALINes | LFIeld1 |
LFIeld2 | LALTernate}
:TRIGger:TV:POLarity
<polarity> (see
page 699)
:TRIGger:TV:POLarity?
(see page 699)
<polarity> ::= {POSitive |
NEGative}
:TRIGger:TV:SOURce
<source> (see
page 700)
:TRIGger:TV:SOURce?
(see page 700)
<source> ::= {CHANnel<n>}
<n> ::= 1 to (# analog channels)
in NR1 format
:TRIGger:TV:STANdard
<standard> (see
page 701)
:TRIGger:TV:STANdard?
(see page 701)
<standard> ::= {NTSC | PAL | PALM
| SECam}
Table 50 :TRIGger:USB Commands Summary
Command Query Options and Query Returns
:TRIGger:USB:SOURce:D
MINus <source> (see
page 703)
:TRIGger:USB:SOURce:D
MINus? (see page 703)
<source> ::= {CHANnel<n> |
EXTernal} for the DSO models
<source> ::= {CHANnel<n> |
DIGital<d>} for the MSO models
<n> ::= 1 to (# analog channels)
in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
:TRIGger:USB:SOURce:D
PLus <source> (see
page 704)
:TRIGger:USB:SOURce:D
PLus? (see page 704)
<source> ::= {CHANnel<n> |
EXTernal} for the DSO models
<source> ::= {CHANnel<n> |
DIGital<d>} for the MSO models
<n> ::= 1 to (# analog channels)
in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
:TRIGger:USB:SPEed
<value> (see
page 705)
:TRIGger:USB:SPEed?
(see page 705)
<value> ::= {LOW | FULL}
:TRIGger:USB:TRIGger
<value> (see
page 706)
:TRIGger:USB:TRIGger?
(see page 706)
<value> ::= {SOP | EOP |
ENTersuspend | EXITsuspend |
RESet}
