Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide 107
Table 39 :SYSTem Commands Summary
Command Query Options and Query Returns
:SYSTem:DATE <date>
(see page 617)
:SYSTem:DATE? (see
page 617)
<date> ::= <year>,<month>,<day>
<year> ::= 4-digit year in NR1
format
<month> ::= {1,..,12 | JANuary |
FEBruary | MARch | APRil | MAY |
JUNe | JULy | AUGust | SEPtember
| OCTober | NOVember | DECember}
<day> ::= {1,..31}
:SYSTem:DSP <string>
(see page 618)
n/a <string> ::= up to 75 characters
as a quoted ASCII string
n/a :SYSTem:ERRor? (see
page 619)
<error> ::= an integer error code
<error string> ::= quoted ASCII
string.
See Error Messages (see
page 821).
:SYSTem:LOCK <value>
(see page 620)
:SYSTem:LOCK? (see
page 620)
<value> ::= {{1 | ON} | {0 |
OFF}}
:SYSTem:PRESet (see
page 621)
n/a See :SYSTem:PRESet (see
page 621)
:SYSTem:PROTection:LO
CK <value> (see
page 624)
:SYSTem:PROTection:LO
CK? (see page 624)
<value> ::= {{1 | ON} | {0 |
OFF}}
:SYSTem:SETup
<setup_data> (see
page 625)
:SYSTem:SETup? (see
page 625)
<setup_data> ::= data in IEEE
488.2 # format.
:SYSTem:TIME <time>
(see page 627)
:SYSTem:TIME? (see
page 627)
<time> ::= hours,minutes,seconds
in NR1 format
Table 40 :TIMebase Commands Summary
Command Query Options and Query Returns
:TIMebase:MODE
<value> (see
page 631)
:TIMebase:MODE? (see
page 631)
<value> ::= {MAIN | WINDow | XY |
ROLL}
:TIMebase:POSition
<pos> (see page 632)
:TIMebase:POSition?
(see page 632)
<pos> ::= time from the trigger
event to the display reference
point in NR3 format
:TIMebase:RANGe
<range_value> (see
page 633)
:TIMebase:RANGe? (see
page 633)
<range_value> ::= 20 ns through
500 s in NR3 format
