104 Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide
4 Commands Quick Reference
:SEARch:SERial:I2S:PA
TTern:DATA <string>
(see page 591)
:SEARch:SERial:I2S:PA
TTern:DATA? (see
page 591)
<string> ::= "n" where n ::=
32-bit integer in signed decimal
when <base> = DECimal
<string> ::= "nn...n" where n ::=
{0 | 1 | X} when <base> = BINary
<string> ::= "0xnn...n" where n
::= {0,..,9 | A,..,F | X} when
<base> = HEX
:SEARch:SERial:I2S:PA
TTern:FORMat <base>
(see page 592)
:SEARch:SERial:I2S:PA
TTern:FORMat? (see
page 592)
<base> ::= {BINary | HEX |
DECimal}
:SEARch:SERial:I2S:RA
NGe <upper>, <lower>
(see page 593)
:SEARch:SERial:I2S:RA
NGe? (see page 593)
<upper> ::= 32-bit integer in
signed decimal, <nondecimal>, or
<string>
<lower> ::= 32-bit integer in
signed decimal, <nondecimal>, or
<string>
<nondecimal> ::= #Hnn...n where n
::= {0,..,9 | A,..,F} for
hexadecimal
<nondecimal> ::= #Bnn...n where n
::= {0 | 1} for binary
<string> ::= "0xnn...n" where n
::= {0,..,9 | A,..,F} for
hexadecimal
Table 34 :SEARch:SERial:I2S Commands Summary (continued)
Command Query Options and Query Returns
Table 35 :SEARch:SERial:IIC Commands Summary
Command Query Options and Query Returns
:SEARch:SERial:IIC:MO
DE <value> (see
page 595)
:SEARch:SERial:IIC:MO
DE? (see page 595)
<value> ::= { READ7 | WRITE7 |
NACKnowledge | ANACk | R7Data2 |
W7Data2 | RESTart | READEprom}
:SEARch:SERial:IIC:PA
TTern:ADDRess <value>
(see page 597)
:SEARch:SERial:IIC:PA
TTern:ADDRess? (see
page 597)
<value> ::= integer or <string>
<string> ::= "0xnn" n ::= {0,..,9
| A,..,F}
:SEARch:SERial:IIC:PA
TTern:DATA <value>
(see page 598)
:SEARch:SERial:IIC:PA
TTern:DATA? (see
page 598)
<value> ::= integer or <string>
<string> ::= "0xnn" n ::= {0,..,9
| A,..,F}
