Commands Quick Reference 4
Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide 103
:SEARch:TRANsition:SO
URce <source> (see
page 580)
:SEARch:TRANsition:SO
URce? (see page 580)
<source> ::= CHANnel<n>
<n> ::= 1 to (# analog channels)
in NR1 format
:SEARch:TRANsition:TI
ME <time>[suffix]
(see page 581)
:SEARch:TRANsition:TI
ME? (see page 581)
<time> ::= floating-point number
in NR3 format
[suffix] ::= {s | ms | us | ns |
ps}
Table 32 :SEARch:TRANsition Commands Summary (continued)
Command Query Options and Query Returns
Table 33 :SEARch:SERial:CAN Commands Summary
Command Query Options and Query Returns
:SEARch:SERial:CAN:MO
DE <value> (see
page 587)
:SEARch:SERial:CAN:MO
DE? (see page 587)
<value> ::= {DATA | IDData |
IDEither | IDRemote | ALLerrors |
OVERload | ERRor}
:SEARch:SERial:CAN:PA
TTern:DATA <string>
(see page 583)
:SEARch:SERial:CAN:PA
TTern:DATA? (see
page 583)
<string> ::= "0xnn...n" where n
::= {0,..,9 | A,..,F | X} for
hexadecimal
:SEARch:SERial:CAN:PA
TTern:DATA:LENGth
<length> (see
page 584)
:SEARch:SERial:CAN:PA
TTern:DATA:LENGth?
(see page 584)
<length> ::= integer from 1 to 8
in NR1 format
:SEARch:SERial:CAN:PA
TTern:ID <string>
(see page 585)
:SEARch:SERial:CAN:PA
TTern:ID? (see
page 585)
<string> ::= "0xnn...n" where n
::= {0,..,9 | A,..,F | X} for
hexadecimal
:SEARch:SERial:CAN:PA
TTern:ID:MODE <value>
(see page 586)
:SEARch:SERial:CAN:PA
TTern:ID:MODE? (see
page 586)
<value> ::= {STANdard | EXTended}
Table 34 :SEARch:SERial:I2S Commands Summary
Command Query Options and Query Returns
:SEARch:SERial:I2S:AU
Dio <audio_ch> (see
page 589)
:SEARch:SERial:I2S:AU
Dio? (see page 589)
<audio_ch> ::= {RIGHt | LEFT |
EITHer}
:SEARch:SERial:I2S:MO
DE <value> (see
page 590)
:SEARch:SERial:I2S:MO
DE? (see page 590)
<value> ::= {EQUal | NOTequal |
LESSthan | GREaterthan | INRange
| OUTRange}
