Commands Quick Reference 4
Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide 101
Table 28 General :SEARch Commands Summary
Command Query Options and Query Returns
n/a :SEARch:COUNt? (see
page 559)
<count> ::= an integer count
value
:SEARch:MODE <value>
(see page 560)
:SEARch:MODE? (see
page 560)
<value> ::= {EDGE | GLITch | RUNT
| TRANsition | SERial{1 | 2}}
:SEARch:STATe <value>
(see page 561)
:SEARch:STATe? (see
page 561)
<value> ::= {{0 | OFF} | {1 |
ON}}
Table 29 :SEARch:EDGE Commands Summary
Command Query Options and Query Returns
:SEARch:EDGE:SLOPe
<slope> (see
page 563)
:SEARch:EDGE:SLOPe?
(see page 563)
<slope> ::= {POSitive | NEGative
| EITHer}
:SEARch:EDGE:SOURce
<source> (see
page 564)
:SEARch:EDGE:SOURce?
(see page 564)
<source> ::= CHANnel<n>
<n> ::= 1 to (# analog channels)
in NR1 format
Table 30 :SEARch:GLITch Commands Summary
Command Query Options and Query Returns
:SEARch:GLITch:GREate
rthan
<greater_than_time>[s
uffix] (see page 566)
:SEARch:GLITch:GREate
rthan? (see page 566)
<greater_than_time> ::=
floating-point number in NR3
format
[suffix] ::= {s | ms | us | ns |
ps}
:SEARch:GLITch:LESSth
an
<less_than_time>[suff
ix] (see page 567)
:SEARch:GLITch:LESSth
an? (see page 567)
<less_than_time> ::=
floating-point number in NR3
format
[suffix] ::= {s | ms | us | ns |
ps}
:SEARch:GLITch:POLari
ty <polarity> (see
page 568)
:SEARch:GLITch:POLari
ty? (see page 568)
<polarity> ::= {POSitive |
NEGative}
:SEARch:GLITch:QUALif
ier <qualifier> (see
page 569)
:SEARch:GLITch:QUALif
ier? (see page 569)
<qualifier> ::= {GREaterthan |
LESSthan | RANGe}
