16 Multimode Source for 6510 Q-TOF LC/MS Set-Up Guide
1 Installation
To convert from ESI or APCI to the multimode source
Figure 11 Standard spray shield and capillary cap for ESI or APCI
8 Remove the capillary cap. If needed, moisten a clean cloth with isopropyl
alcohol and wipe the capillary cap. See Figure 12.
Figure 12 Spray shield removed.
9 Place the capillary cap back on the capillary.
10 Install the new spray shield with field shaping electrodes. See Figure 13.
Standard spray shield
Capillary cap
Capillary cap
