1. Press [Utility] > {GPIB/RS-232 LAN} >

{RS-232 Setup}.

2. Press {RS-232 Baud Rate}. Press the desired baud rate softkey to set the

baud rate.

3. Press {RS-232 Echo Off On}. This toggles the state of the SCPI echoing on the

RS-232 connection. Set as desired.

4. Press {Trans/Recv Pace None Xon}. This toggles from no handshaking

(Trans/Recv Pace None) to XON/XOFF

handshaking (Trans/Recv Pace Xon) when

transmitting or receiving data via RS-232.

Set as desired.

5. Press {Reset RS-232}. This deletes the data from the RS-232 buffer.

Pressing this key will discard any unprocessed

SCPI input received over RS-232.

These RS-232 parameters are not affected by an

instrument preset or by a power cycle.

Configuring for a serial (RS-232)

auxiliary interface
