This section will show you how to
configure the signal generator to
interface with a remote controller.
Follow the instructions in the appro-
priate section to configure your PSG
signal generator for remote control.
NOTE For a complete system
interface required equipment list
and installation procedure, see the
programming guide.
Configuring for a parallel GPIB
(IEEE 488.2, 1987) interface
Selecting a GPIB Address
Instruction Note
1. Press [Utility] > {GPIB/RS-232} > {GPIB Address}.
2. Use the numeric keypad, the arrow keys, or
rotate the front panel knob to set the desired address.
3. Press {Enter}.
The signal generator’s GPIB address is set to 19
at the factory. The acceptable range of addresses
is 0 through 30. The state of the GPIB address is
not affected by a signal generator preset or by
a power cycle.
Instruction Note
1. Press [Utility] > {GPIB/RS-232 LAN} > {LAN Setup}.
2. Press {Hostname}. Use the alphanumeric softkeys to enter
a hostname.
3. Press {Enter}.
4. Press {IP Address}. Use the left and right arrow keys to move the
cursor. Use the up and down arrow keys, the front
panel knob or the numeric keypad to enter an
IP address.
5. Press {Enter}. This assigns a hostname and IP address to the
signal generator. The hostname and IP address are
not affected by an instrument preset or by a
power cycle.
Part 6: Configuring for
Remote Control
Configuring for a LAN
(10-base T) interface
