Setting Up the Analyzer
Sample Program
3. Setting Up the Analyzer
550 Scale1(4)=2 ! Trace4: 2
560 Scale2(1)=10 ! Ch.2 Trace1: 10 dBm
570 Scale2(2)=2 ! Trace2: 2
580 File$="Ex_3_1.sta" ! Save File Name : Ex_3_1.sta
590 !
600 OUTPUT @Agte507x;":SYST:PRES"
610 !
620 OUTPUT @Agte507x;":DISP:SPL D1_1_2"
630 OUTPUT @Agte507x;":INIT1:CONT ON"
640 OUTPUT @Agte507x;":INIT2:CONT ON"
650 !
660 ! Channel 1
670 !
680 OUTPUT @Agte507x;":SENS1:SWE:TYPE SEGM"
690 OUTPUT @Agte507x;":SENS1:SEGM:DATA 5,0,1,1,0,0,";Segm;",";
700 FOR I=1 TO Segm-1
710 OUTPUT
@Agte507x;Star1(I);",";Stop1(I);",";Nop1(I);",";If_bw1(I);",";Pow1(I);",
";
720 NEXT I
730 OUTPUT
@Agte507x;Star1(Segm);",";Stop1(Segm);",";Nop1(Segm);",";If_bw1(Segm);",
";Pow(Segm)
740 !
750 OUTPUT @Agte507x;":CALC1:PAR:COUN ";Num_of_tr1
760 OUTPUT @Agte507x;":DISP:WIND1:SPL "&Allocate1$
770 FOR I=1 TO Num_of_tr1
780 OUTPUT @Agte507x;":CALC1:PAR"&VAL$(I)&":DEF "&Para1$(I)
790 OUTPUT @Agte507x;":CALC1:PAR"&VAL$(I)&":SEL"
800 OUTPUT @Agte507x;":CALC1:FORM "&Fmt1$(I)
810 SELECT Fmt1$(I)
820 CASE "SLIN","SLOG","SCOM","SMIT","SADM","PLIN","PLOG","POL"
830 OUTPUT @Agte507x;":DISP:WIND1:TRAC"&VAL$(I)&":Y:PDIV
";Scale1(I)
840 CASE ELSE
850 OUTPUT @Agte507x;":DISP:WIND1:TRAC"&VAL$(I)&":Y:RPOS
";Ref_pos1(I)
860 OUTPUT @Agte507x;":DISP:WIND1:TRAC"&VAL$(I)&":Y:RLEV
";Ref_rev1(I)
870 OUTPUT @Agte507x;":DISP:WIND1:TRAC"&VAL$(I)&":Y:PDIV
";Scale1(I)
880 END SELECT
890 NEXT I
900 !
910 ! Channel 2
920 !
921 PAUSE
930 OUTPUT @Agte507x;":SENS2:SWE:TYPE LIN"
940 OUTPUT @Agte507x;":SENS2:FREQ:CENT ";Cent2
950 OUTPUT @Agte507x;":SENS2:FREQ:SPAN ";Span2
960 OUTPUT @Agte507x;":SENS2:SWE:POIN ";Nop2
970 OUTPUT @Agte507x;":SENS2:BAND ";If_bw2
980 OUTPUT @Agte507x;":SOUR2:POW ";Pow2
990 !
1000 OUTPUT @Agte507x;":CALC2:PAR:COUN ";Num_of_tr2
1010 OUTPUT @Agte507x;":DISP:WIND2:SPL "&Allocate2$
1020 FOR I=1 TO Num_of_tr2
1030 OUTPUT @Agte507x;":CALC2:PAR"&VAL$(I)&":DEF "&Para2$(I)
