User`s guide
Table Of Contents
- Agilent E5061A/E5062A ENA Series ENA Series RF Network Analyzers
- 1 Making Effective Use of This Manual
- 2 Overview of Remote Control
- 3 Setting Up the Analyzer
- 4 Performing a Calibration
- 5 Making a Measurement
- 6 Analyzing Data
- 7 Reading/Writing Measurement Data
- 8 Limit Test
- 9 Saving and Recalling (File Management)
- 10 Communication with External Instruments Using Handler I/O Port
- 11 Working with Automatic Test Systems
- 12 Sample Application Programs
- 13 SCPI Command Reference
- Notational conventions in this command reference
- IEEE Common Commands
- E5061A/E5062A commands
- :ABOR
- :CALC{1-4}:BLIM
- :CALC{1-4}:BLIM:DB
- :CALC{1-4}:BLIM:DISP:MARK
- :CALC{1-4}:BLIM:DISP:VAL
- :CALC{1-4}:BLIM:FAIL?
- :CALC{1-4}:BLIM:MAX
- :CALC{1-4}:BLIM:MIN
- :CALC{1-4}:BLIM:REP?
- :CALC{1-4}:CONV
- :CALC{1-4}:CONV:FUNC
- :CALC{1-4}:CORR:EDEL:TIME
- :CALC{1-4}:CORR:OFFS:PHAS
- :CALC{1-4}:DATA:FDAT
- :CALC{1-4}:DATA:FMEM
- :CALC{1-4}:DATA:SDAT
- :CALC{1-4}:DATA:SMEM
- :CALC{1-4}:FORM
- :CALC{1-4}:FUNC:DATA?
- :CALC{1-4}:FUNC:DOM
- :CALC{1-4}:FUNC:DOM:COUP
- :CALC{1-4}:FUNC:DOM:STAR
- :CALC{1-4}:FUNC:DOM:STOP
- :CALC{1-4}:FUNC:EXEC
- :CALC{1-4}:FUNC:PEXC
- :CALC{1-4}:FUNC:POIN?
- :CALC{1-4}:FUNC:PPOL
- :CALC{1-4}:FUNC:TARG
- :CALC{1-4}:FUNC:TTR
- :CALC{1-4}:FUNC:TYPE
- :CALC{1-4}:LIM
- :CALC{1-4}:LIM:DATA
- :CALC{1-4}:LIM:DISP
- :CALC{1-4}:LIM:DISP:CLIP
- :CALC{1-4}:LIM:FAIL?
- :CALC{1-4}:LIM:OFFS:AMPL
- :CALC{1-4}:LIM:OFFS:MARK
- :CALC{1-4}:LIM:OFFS:STIM
- :CALC{1-4}:LIM:REP:ALL?
- :CALC{1-4}:LIM:REP?
- :CALC{1-4}:LIM:REP:POIN?
- :CALC{1-4}:MARK:BWID
- :CALC{1-4}:MARK:COUP
- :CALC{1-4}:MARK:FUNC:DOM
- :CALC{1-4}:MARK:FUNC:DOM:COUP
- :CALC{1-4}:MARK:FUNC:DOM:STAR
- :CALC{1-4}:MARK:FUNC:DOM:STOP
- :CALC{1-4}:MARK:FUNC:MULT:PEXC
- :CALC{1-4}:MARK:FUNC:MULT:PPOL
- :CALC{1-4}:MARK:FUNC:MULT:TARG
- :CALC{1-4}:MARK:FUNC:MULT:TRAC
- :CALC{1-4}:MARK:FUNC:MULT:TTR
- :CALC{1-4}:MARK:FUNC:MULT:TYPE
- :CALC{1-4}:MARK:MATH:FLAT
- :CALC{1-4}:MARK:MATH:FLAT:DATA?
- :CALC{1-4}:MARK:MATH:FST
- :CALC{1-4}:MARK:MATH:FST:DATA?
- :CALC{1-4}:MARK:MATH:STAT
- :CALC{1-4}:MARK:MATH:STAT:DATA?
- :CALC{1-4}:MARK:NOTC
- :CALC{1-4}:MARK:REF
- :CALC{1-4}:MARK{1-10}
- :CALC{1-4}:MARK{1-10}:ACT
- :CALC{1-4}:MARK{1-10}:BWID:DATA?
- :CALC{1-4}:MARK{1-10}:BWID:THR
- :CALC{1-4}:MARK{1-10}:DISC
- :CALC{1-4}:MARK{1-10}:FUNC:EXEC
- :CALC{1-4}:MARK{1-10}:FUNC:PEXC
- :CALC{1-4}:MARK{1-10}:FUNC:PPOL
- :CALC{1-4}:MARK{1-10}:FUNC:TARG
- :CALC{1-4}:MARK{1-10}:FUNC:TRAC
- :CALC{1-4}:MARK{1-10}:FUNC:TTR
- :CALC{1-4}:MARK{1-10}:FUNC:TYPE
- :CALC{1-4}:MARK{1-10}:NOTC:DATA?
- :CALC{1-4}:MARK{1-10}:NOTC:THR
- :CALC{1-4}:MARK{1-10}:SET
- :CALC{1-4}:MARK{1-10}:X
- :CALC{1-4}:MARK{1-10}:Y?
- :CALC{1-4}:MATH:FUNC
- :CALC{1-4}:MATH:MEM
- :CALC{1-4}:MST
- :CALC{1-4}:MST:DATA?
- :CALC{1-4}:PAR:COUN
- :CALC{1-4}:PAR{1-4}:DEF
- :CALC{1-4}:PAR{1-4}:SEL
- :CALC{1-4}:RLIM
- :CALC{1-4}:RLIM:DATA
- :CALC{1-4}:RLIM:DISP:LINE
- :CALC{1-4}:RLIM:DISP:SEL
- :CALC{1-4}:RLIM:DISP:VAL
- :CALC{1-4}:RLIM:FAIL?
- :CALC{1-4}:RLIM:REP?
- :CALC{1-4}:SMO
- :CALC{1-4}:SMO:APER
- :CONT:HAND:A
- :CONT:HAND:B
- :CONT:HAND:C
- :CONT:HAND:C:MODE
- :CONT:HAND:D
- :CONT:HAND:D:MODE
- :CONT:HAND:E
- :CONT:HAND:F
- :CONT:HAND:IND:STAT
- :CONT:HAND:OUTP{1-2}
- :CONT:HAND:RTR:STAT
- :DISP:ANN:FREQ
- :DISP:CCL
- :DISP:CLOC
- :DISP:COL{1-2}:BACK
- :DISP:COL{1-2}:GRAT{1-2}
- :DISP:COL{1-2}:LIM{1-2}
- :DISP:COL{1-2}:RES
- :DISP:COL{1-2}:TRAC{1-4}:DATA
- :DISP:COL{1-2}:TRAC{1-4}:MEM
- :DISP:ECHO
- :DISP:ECHO:CLE
- :DISP:ENAB
- :DISP:FSIG
- :DISP:IMAG
- :DISP:MAX
- :DISP:SKEY
- :DISP:SPL
- :DISP:TABL
- :DISP:TABL:TYPE
- :DISP:UPD
- :DISP:WIND{1-4}:ACT
- :DISP:WIND{1-4}:ANN:MARK:ALIG
- :DISP:WIND{1-4}:ANN:MARK:SING
- :DISP:WIND{1-4}:LAB
- :DISP:WIND{1-4}:MAX
- :DISP:WIND{1-4}:SPL
- :DISP:WIND{1-4}:TITL
- :DISP:WIND{1-4}:TITL:DATA
- :DISP:WIND{1-4}:TRAC{1-4}:ANN:MARK:POS:X
- :DISP:WIND{1-4}:TRAC{1-4}:ANN:MARK:POS:Y
- :DISP:WIND{1-4}:TRAC{1-4}:ANN:YAX:MODE
- :DISP:WIND{1-4}:TRAC{1-4}:MEM
- :DISP:WIND{1-4}:TRAC{1-4}:STAT
- :DISP:WIND{1-4}:TRAC{1-4}:Y:AUTO
- :DISP:WIND{1-4}:TRAC{1-4}:Y:PDIV
- :DISP:WIND{1-4}:TRAC{1-4}:Y:RLEV
- :DISP:WIND{1-4}:TRAC{1-4}:Y:RPOS
- :DISP:WIND{1-4}:TRAC{1-4}:Y:TRAC:FREQ
- :DISP:WIND{1-4}:TRAC{1-4}:Y:TRAC:MODE
- :DISP:WIND{1-4}:X:SPAC
- :DISP:WIND{1-4}:Y:DIV
- :FORM:BORD
- :FORM:DATA
- :HCOP
- :HCOP:ABOR
- :HCOP:IMAG
- :INIT{1-4}
- :INIT{1-4}:CONT
- :MMEM:CAT?
- :MMEM:COPY
- :MMEM:DEL
- :MMEM:LOAD
- :MMEM:LOAD:CHAN
- :MMEM:LOAD:CHAN:COEF
- :MMEM:LOAD:LIM
- :MMEM:LOAD:PROG
- :MMEM:LOAD:RLIM
- :MMEM:LOAD:SEGM
- :MMEM:MDIR
- :MMEM:STOR
- :MMEM:STOR:CHAN
- :MMEM:STOR:CHAN:CLE
- :MMEM:STOR:CHAN:COEF
- :MMEM:STOR:FDAT
- :MMEM:STOR:IMAG
- :MMEM:STOR:LIM
- :MMEM:STOR:PROG
- :MMEM:STOR:RLIM
- :MMEM:STOR:SALL
- :MMEM:STOR:SEGM
- :MMEM:STOR:STYP
- :MMEM:TRAN
- :OUTP
- :PROG:CAT?
- :PROG:NAME
- :PROG:STAT
- :SENS:CORR:COLL:ECAL:PATH?
- :SENS:CORR:IMP
- :SENS{1-4}:AVER:CLE
- :SENS{1-4}:AVER
- :SENS{1-4}:AVER:COUN
- :SENS{1-4}:BAND
- :SENS{1-4}:BWID
- :SENS{1-4}:CORR:CLE
- :SENS{1-4}:CORR:COEF?
- :SENS{1-4}:CORR:COLL:CKIT
- :SENS{1-4}:CORR:COLL:CKIT:LAB
- :SENS{1-4}:CORR:COLL:CKIT:ORD:LOAD
- :SENS{1-4}:CORR:COLL:CKIT:ORD:OPEN
- :SENS{1-4}:CORR:COLL:CKIT:ORD:SHOR
- :SENS{1-4}:CORR:COLL:CKIT:ORD:THRU
- :SENS{1-4}:CORR:COLL:CKIT:RES
- :SENS{1-4}:CORR:COLL:CKIT:STAN{1-21}:ARB
- :SENS{1-4}:CORR:COLL:CKIT:STAN{1-21}:C0
- :SENS{1-4}:CORR:COLL:CKIT:STAN{1-21}:C1
- :SENS{1-4}:CORR:COLL:CKIT:STAN{1-21}:C2
- :SENS{1-4}:CORR:COLL:CKIT:STAN{1-21}:C3
- :SENS{1-4}:CORR:COLL:CKIT:STAN{1-21}:DEL
- :SENS{1-4}:CORR:COLL:CKIT:STAN{1-21}:L0
- :SENS{1-4}:CORR:COLL:CKIT:STAN{1-21}:L1
- :SENS{1-4}:CORR:COLL:CKIT:STAN{1-21}:L2
- :SENS{1-4}:CORR:COLL:CKIT:STAN{1-21}:L3
- :SENS{1-4}:CORR:COLL:CKIT:STAN{1-21}:LAB
- :SENS{1-4}:CORR:COLL:CKIT:STAN{1-21}:LOSS
- :SENS{1-4}:CORR:COLL:CKIT:STAN{1-21}:TYPE
- :SENS{1-4}:CORR:COLL:CKIT:STAN{1-21}:Z0
- :SENS{1-4}:CORR:COLL:ECAL:ERES
- :SENS{1-4}:CORR:COLL:ECAL:ISOL
- :SENS{1-4}:CORR:COLL:ECAL:SOLT1
- :SENS{1-4}:CORR:COLL:ECAL:SOLT2
- :SENS{1-4}:CORR:COLL:ECAL:THRU
- :SENS{1-4}:CORR:COLL:ISOL
- :SENS{1-4}:CORR:COLL:METH:ERES
- :SENS{1-4}:CORR:COLL:LOAD
- :SENS{1-4}:CORR:COLL:METH:OPEN
- :SENS{1-4}:CORR:COLL:METH:SHOR
- :SENS{1-4}:CORR:COLL:METH:SOLT1
- :SENS{1-4}:CORR:COLL:METH:SOLT2
- :SENS{1-4}:CORR:COLL:METH:THRU
- :SENS{1-4}:CORR:COLL:METH:TYPE?
- :SENS{1-4}:CORR:COLL:OPEN
- :SENS{1-4}:CORR:COLL:SAVE
- :SENS{1-4}:CORR:COLL:SHOR
- :SENS{1-4}:CORR:COLL:THRU
- :SENS{1-4}:CORR:EXT
- :SENS{1-4}:CORR:EXT:PORT{1-2}
- :SENS{1-4}:CORR:PROP
- :SENS{1-4}:CORR:RVEL:COAX
- :SENS{1-4}:CORR:STAT
- :SENS{1-4}:CORR:TYPE{1-4}?
- :SENS{1-4}:FREQ
- :SENS{1-4}:FREQ:CENT
- :SENS{1-4}:FREQ:DATA?
- :SENS{1-4}:FREQ:SPAN
- :SENS{1-4}:FREQ:STAR
- :SENS{1-4}:FREQ:STOP
- :SENS{1-4}:ROSC:SOUR?
- :SENS{1-4}:SEGM:DATA
- :SENS{1-4}:SEGM:SWE:POIN?
- :SENS{1-4}:SEGM:SWE:TIME?
- :SENS{1-4}:SWE:DEL
- :SENS{1-4}:SWE:POIN
- :SENS{1-4}:SWE:TIME
- :SENS{1-4}:SWE:TIME:AUTO
- :SENS{1-4}:SWE:TYPE
- :SERV:CHAN:ACT?
- :SERV:CHAN:COUN?
- :SERV:CHAN{1-4}:TRAC:ACT?
- :SERV:CHAN:TRAC:COUN?
- :SERV:PORT:COUN?
- :SOUR{1-4}:POW
- :SOUR{1-4}:POW:ATT
- :SOUR{1-4}:POW:CENT
- :SOUR{1-4}:POW:PORT:COUP
- :SOUR{1-4}:POW:PORT{1-2}
- :SOUR{1-4}:POW:SLOP
- :SOUR{1-4}:POW:SLOP:STAT
- :SOUR{1-4}:POW:SPAN
- :SOUR{1-4}:POW:STAR
- :SOUR{1-4}:POW:STOP
- :STAT:OPER?
- :STAT:OPER:COND?
- :STAT:OPER:ENAB
- :STAT:OPER:NTR
- :STAT:OPER:PTR
- :STAT:PRES
- :STAT:QUES?
- :STAT:QUES:BLIM?
- :STAT:QUES:BLIM:CHAN{1-4}?
- :STAT:QUES:BLIM:CHAN{1-4}:COND?
- :STAT:QUES:BLIM:CHAN{1-4}:ENAB
- :STAT:QUES:BLIM:CHAN{1-4}:NTR
- :STAT:QUES:BLIM:CHAN{1-4}:PTR
- :STAT:QUES:BLIM:COND?
- :STAT:QUES:BLIM:ENAB
- :STAT:QUES:BLIM:NTR
- :STAT:QUES:BLIM:PTR
- :STAT:QUES:COND?
- :STAT:QUES:ENAB
- :STAT:QUES:LIM?
- :STAT:QUES:LIM:CHAN{1-4}?
- :STAT:QUES:LIM:CHAN{1-4}:COND?
- :STAT:QUES:LIM:CHAN{1-4}:ENAB
- :STAT:QUES:LIM:CHAN{1-4}:NTR
- :STAT:QUES:LIM:CHAN{1-4}:PTR
- :STAT:QUES:LIM:COND?
- :STAT:QUES:LIM:ENAB
- :STAT:QUES:LIM:NTR
- :STAT:QUES:LIM:PTR
- :STAT:QUES:NTR
- :STAT:QUES:PTR
- :STAT:QUES:RLIM?
- :STAT:QUES:RLIM:CHAN{1-4}?
- :STAT:QUES:RLIM:CHAN{1-4}:COND?
- :STAT:QUES:RLIM:CHAN{1-4}:ENAB
- :STAT:QUES:RLIM:CHAN{1-4}:NTR
- :STAT:QUES:RLIM:CHAN{1-4}:PTR
- :STAT:QUES:RLIM:COND?
- :STAT:QUES:RLIM:ENAB
- :STAT:QUES:RLIM:NTR
- :STAT:QUES:RLIM:PTR
- :SYST:BACK
- :SYST:BEEP:COMP:IMM
- :SYST:BEEP:COMP:STAT
- :SYST:BEEP:WARN:IMM
- :SYST:BEEP:WARN:STAT
- :SYST:DATE
- :SYST:ERR?
- :SYST:KLOC:KBD
- :SYST:KLOC:MOUS
- :SYST:POFF
- :SYST:PRES
- :SYST:SEC:LEV
- :SYST:SERV?
- :SYST:TIME
- :SYST:UPR
- :TRIG
- :TRIG:SING
- :TRIG:SOUR
- Command list
- A Manual Changes
- B Status Reporting System
- C Error Messages
- Index
Index
Index 549
Index
Importing, 134
Standard name, 64
Standard type, 64
Standard value, 64
Start value
Frequency sweep range, 41
Marker search range, 91
Power sweep range, 43
Search(analysis) range, 93
Starting a measurement, 83
Statistical analysis results
Analysis command, 94
Statistical analysis, 100
Status byte register, 507
Bit definitions, 516
Reading out, 201
Status register
Example of use
Error detection, 166
Obtaining test results, 121
Waiting for the end of measurement, 84
Register structure, 509
Status reporting system, 506
Stimulus, 41
Stimulus data arrays, 110
Stimulus signal output
On/Off, 41
Stop value
Frequency sweep range, 41
Marker search range, 91
Power sweep range, 43
Search(analysis) range, 93
Sweep condition, 41
Sweep delay time, 42
Sweep range, 41
Power sweep, 43
Sweep time, 42
Reading out
Linear sweep, 426
Segment sweep, 423
Sweep type, 41
SWR format, 47
System Z0, 43
T
Table
Limit table
Showing/hiding, 46
Marker list table, 46
Segment sweep table
Setting, 42
Showing/hiding, 46
Target search
Analysis command, 93
Marker search, 91
telnet, 34
Telnet server
Example of use, 184
Turning on/off, 27
telnet server
Turning on/off, 33
Test results, 121
Each channel, 122
Each measurement point, 121
Each trace, 121
Overall test result, 124
THRU, 65
Time
Show or hide, 49
Timing chart, 155
Total number of measurement points of all segments, 423
Total sweep time of all segments, 423
Trace display, 44
Tracking, 92
Transferring files
Command, 139
Sample program, 140
Transition filter, 508
Transitional direction
Analysis command, 94
Marker search, 92
trg_sing.htb, 88
Trigger source, 81
Trigger system, 80
Triggering a measurement, 83
Turning on or off error correction, 62
Turning on or off the backlight, 49
Turning on or off the port extension, 409
Turns off the analyzer, 479
Typeface conventions, 3
Types of remote control system, 24
U
Update of the LCD display, 163
Turning on or off, 163
Update once, 163
Update on/off
Screen display, 49
User form
Importing, 134
V
VBA, 24
VBA macro
Control, 367
VBA project
Saving/loading, 134
VEE, 35
Velocity factor, 411
W
Waiting for the end of measurement
Inserting wait time, 88
