Appendix B 517
Status Reporting System
Status Register Structure
B. Status Reporting System
Issuing the *CLS command will clear all bits from the standard event status register.
Table B-2 Status Bit Definitions of Event Status Register (ESR)
Bit
Position
Name Description
0 Operation Complete Set to “1” upon completion of all operations done by
commands that precede the *OPC? command on
page 198 command.
1 Not used Always 0
2 Query Error 1. Set to “1” when the E5061A/E5062A receives a data
output request but there is no data to output.
2. Set to “1” when the data of the E5061A/E5062A's
output queue has been cleared because of a new
message received before the completion of data
output.
3 Instrument Dependent Error Set to “1” when an error has occurred and the error is not a
command, query, or execution error.
4 Execution Error 1. Set to “1” when any parameter in an SCPI command
exceeds its input range or is inconsistent with the
E5061A/E5062A's capabilities.
2. Set to “1” when an SCPI command cannot be
properly executed due to some condition of the
E5061A/E5062A.
5 Command Error 1. Set to “1” when an IEEE 488.2 syntax error occurs (a
command sent to the E5061A/E5062A does not
follow the IEEE 488.2 syntax). Possible violations
include the command parameter violating the
E5061A/E5062A listening formats or being
unacceptable.
2. Set to “1” when a semantic error occurs. Possible
causes include a command containing misspellings
being sent to the E5061A/E5062A or an IEEE 488.2
command not supported by the E5061A/E5062A
being sent.
3. Set to “1” when GET (Group Execution Trigger) is
input while a program message is being received.
6 Not used Always 0
7 Power ON Set to “1” when the E5061A/E5062A is powered ON, or
when the firmware is restarted.
