Chapter 13 491
SCPI Command Reference
Command list
13. SCPI Command
Reference
DISPlay
:WINDow{[1]|2|3|4}
:ACTivate [No query]
:ANNotation
:MARKer
:ALIGn
[:STATe] {ON|OFF|1|0}
:SINGle
[:STATe] {ON|OFF|1|0}
:LABel {ON|OFF|1|0}
:MAXimize {ON|OFF|1|0}
:SPLit {D1|D12|D1_2|D112|D1_1_2|D123|D1_2_3|D12_33|D11_23|D13_23|
D12_13|D1234|D1_2_3_4|D12_34}
:TITLe
:DATA <string>
[:STATe] {ON|OFF|1|0}
:TRACe{[1]|2|3|4}
:ANNotation
:MARKer
:POSition:X <numeric>
:POSition:Y <numeric>
:YAXis
:MODE {AUTO|RELative}
:MEMory
[:STATe] {ON|OFF|1|0}
:STATe {ON|OFF|1|0}
:Y
[:SCALe]
:AUTO [No query]
:PDIVision <numeric>
:RLEVel <numeric>
:RPOSition <numeric>
:TRACk
:MODE {OFF|PEAK|FREQuency}
:FREQuency <numeric>
:X
:SPACing {LINear|OBASe}
:Y
[:SCALe]
:DIVisions <numeric>
FORMat
:BORDer {NORMal|SWAPped}
:DATA {ASCii|REAL|REAL32}
Table 13-1 E5061A/E5062A SCPI command tree
Command Parameters Note
