Chapter 13 489
SCPI Command Reference
Command list
13. SCPI Command
Reference
CALCulate{[1]|2|3|4}
[:SELected]
:MSTatistics
:DATA? [Query only]
[:STATe] {ON|OFF|1|0}
:RLIMit
:DATA <numeric>,…,<numeric> (1 + number of lines × 4 parameters)
:DISPlay
:LINE {ON|OFF|1|0}
:SELect <numeric>
:VALue {OFF|ABSolute|MARgin}
:FAIL? [Query only]
:REPort
[:DATA]? [Query only]
[:STATe] {ON|OFF|1|0}
:SMOothing
:APERture <numeric>
[:STATe] {ON|OFF|1|0}
:TRANsform
:TIME
:CENTer <numeric>
:IMPulse
:WIDTh <numeric>
:KBESsel <numeric>
:LPFRequency [No query]
:SPAN <numeric>
:STARt <numeric>
:STATe {ON|OFF|1|0}
:STEP
:RTIMe <numeric>
:STIMulus {IMPulse|STEP}
:STOP <numeric>
[:TYPE] {BPASs|LPASs}
CONTrol
:HANDler
:A
[:DATA] <numeric> [No query]
:B
[:DATA] <numeric> [No query]
:C
[:DATA] <numeric>
:MODE {INPut|OUTPut}
:D
[:DATA] <numeric>
:MODE {INPut|OUTPut}
Table 13-1 E5061A/E5062A SCPI command tree
Command Parameters Note
