486 Chapter 13
SCPI Command Reference
Command list
Command list
Command tree
Table 13-1 shows the SCPI command tree of the E5061A/E5062A.
Table 13-1 E5061A/E5062A SCPI command tree
Command Parameters Note
ABORt [No query]
CALCulate{[1]|2|3|4}
:PARameter
:COUNt <numeric>
:PARameter{[1]|2|3|4}
:DEFine {S11|S21|S12|S22}
:SELect [No query]
[:SELected]
:BLIMit
:DB <numeric>
:DISPlay
:MARKer {ON|OFF|1|0}
:VALue {ON|OFF|1|0}
:FAIL? [Query only]
:MAXimum <numeric>
:MINimum <numeric>
:REPort
[:DATA]? [Query only]
[:STATe] {ON|OFF|1|0}
:CONVersion
:FUNCtion {ZREFlection|ZTRansmit|YREFlection|YTRansmit|INVersion}
[:STATe] {ON|OFF|1|0}
:CORRection
:EDELay
:TIME <numeric>
:OFFSet
:PHASe <numeric>
:DATA
:FDATa <numeric>,…,<numeric> (number of measurement points × 2 parameters)
:FMEMory <numeric>,…,<numeric> (number of measurement points × 2 parameters)
:SDATa <numeric>,…,<numeric> (number of measurement points × 2 parameters)
:SMEMory <numeric>,…,<numeric> (number of measurement points × 2 parameters)
:FORMat {MLOGarithmic|PHASe|GDELay|SLINear|SLOGarithmic|
SCOMplex|SMITh|SADMittance|PLINear|PLOGarithmic|
POLar|MLINear|SWR|REAL|IMAGinary|UPHase|PPHase}
