Chapter 13 475
SCPI Command Reference
E5061A/E5062A commands
13. SCPI Command
Reference
:SYST:DATE
Syntax :SYSTem:DATE <numeric 1>,<numeric 2>,<numeric 3>
:SYSTem:DATE?
Description Sets the date of the clock built in the E5061A/E5062A.
Parameters
If the specified parameter is out of the allowable setup range, the minimum value (if the
lower limit of the range is not reached) or the maximum value (if the upper limit of the
range is exceeded) is set.
Query response {numeric 1},{numeric 2},{numeric 3}<newline><^END>
Example of use
10 OUTPUT 717;":SYST:DATE 2002,1,1"
20 OUTPUT 717;":SYST:DATE?"
30 ENTER 717;A,B,C
Related commands :SYST:TIME on page 482
:DISP:CLOC on page 305
Equivalent key
[System] - Misc Setup - Clock Setup - Set Date and Time
<numeric 1> <numeric 2> <numeric 3>
Description Year Month Day
Range 1980 to 2099 1 to 12 1 to 31
Resolution 1 1 1
