474 Chapter 13
SCPI Command Reference
E5061A/E5062A commands
:SYST:BEEP:WARN:IMM
Syntax :SYSTem:BEEPer:WARNing:IMMediate
Description Generates a beep for the notification of warning/limit test result. (No query)
Example of use
10 OUTPUT 717;":SYST:BEEP:WARN:IMM"
Related commands :SYST:BEEP:WARN:STAT on page 474
:SYST:BEEP:COMP:IMM on page 473
Equivalent key
[System] - Misc Setup - Beeper - Test Beep Warning
:SYST:BEEP:WARN:STAT
Syntax :SYSTem:BEEPer:WARNing:STATe {ON|OFF|1|0}
:SYSTem:BEEPer:WARNing:STATe?
Description Turns ON/OFF the beeper for the notification of warning/limit test result.
Parameters
Query response {1|0}<newline><^END>
Example of use
10 OUTPUT 717;":SYST:BEEP:WARN:STAT OFF"
20 OUTPUT 717;":SYST:BEEP:WARN:STAT?"
30 ENTER 717;A
Related commands :SYST:BEEP:WARN:IMM on page 474
:SYST:BEEP:COMP:STAT on page 473
Equivalent key
[System] - Misc Setup - Beeper - Beep Warning
Description
ON or 1 (preset value) Turns ON the beeper.
OFF or 0 Turns OFF the beeper.
