Chapter 13 455
SCPI Command Reference
E5061A/E5062A commands
13. SCPI Command
Reference
:STAT:QUES:LIM?
Syntax :STATus:QUEStionable:LIMit[:EVENt]?
Description Reads out the value of the Questionable Limit Status Event Register. (Query only)
Query response {numeric}<newline><^END>
Example of use
10 OUTPUT 717;":STAT:QUES:LIM?"
20 ENTER 717;A
Related commands *CLS on page 196
Equivalent key No equivalent key is available on the front panel.
:STAT:QUES:LIM:CHAN{1-4}?
Syntax :STATus:QUEStionable:LIMit:CHANnel{[1]|2|3|4}[:EVENt]?
Description Reads out the value of the Questionable Limit Channel Status Event Register of channel 1
(:CHAN1) to channel 4 (:CHAN4). (Query only)
Query response {numeric}<newline><^END>
Example of use
10 OUTPUT 717;":STAT:QUES:LIM:CHAN1?"
20 ENTER 717;A
Related commands *CLS on page 196
Equivalent key No equivalent key is available on the front panel.
:STAT:QUES:LIM:CHAN{1-4}:COND?
Syntax :STATus:QUEStionable:LIMit:CHANnel{[1]|2|3|4}:CONDition?
Description Reads out the value of the Questionable Limit Channel Status Condition Register of
channel 1 (:CHAN1) to channel 4 (:CHAN4). (Query only)
Query response {numeric}<newline><^END>
Example of use
10 OUTPUT 717;":STAT:QUES:LIM:CHAN1:COND?"
20 ENTER 717;A
Related commands :STAT:QUES:LIM:CHAN{1-4}:NTR on page 457
:STAT:QUES:LIM:CHAN{1-4}:PTR on page 458
Equivalent key No equivalent key is available on the front panel.
