428 Chapter 13
SCPI Command Reference
E5061A/E5062A commands
:SENS{1-4}:SWE:TYPE
Syntax :SENSe{[1]|2|3|4}:SWEep:TYPE {LINear|LOGarithmic|SEGMent|POWer}
:SENSe{[1]|2|3|4}:SWEep:TYPE?
Description Sets the sweep type of channel 1 (:SENS1) to channel 4 (:SENS4).
Parameters
Query response {LIN|LOG|SEGM|POW}<newline><^END>
Example of use
10 OUTPUT 717;":SENS1:SWE:TYPE SEGM"
20 OUTPUT 717;":SENS1:SWE:TYPE?"
30 ENTER 717;A$
Equivalent key [Sweep Setup] - Sweep Type - Lin Freq|Log Freq|Segment
:SERV:CHAN:ACT?
Syntax :SERVice:CHANnel:ACTive?
Description Reads out the active channel number. (Query only)
Query response {numeric}<newline><^END>
Example of use
10 OUTPUT 717;":SERV:CHAN:ACT?"
20 ENTER 717;A
Related commands :DISP:WIND{1-4}:ACT on page 318
Equivalent key No equivalent key is available on the front panel.
Description
LINear (preset value) Specifies the linear sweep.
LOGarithmic
Specifies the logarithmic sweep.
*1
SEGMent Specifies the segment sweep.
POWer Specifies the power sweep.
*1.If you execute this command to try to specify the log sweep when the frequency span
condition necessary for the log sweep is not satisfied (the stop frequency is about 4
times or more the start frequency), an error occurs and the command is ignored.
