420 Chapter 13
SCPI Command Reference
E5061A/E5062A commands
:SENS{1-4}:ROSC:SOUR?
Syntax :SENSe{[1]|2|3|4}:ROSCillator:SOURce?
Description Reads out whether the external reference signal is inputted to the Ref In connector on the
rear panel. (Query only)
Query response {INTernal|EXTernal}<newline><^END>
Example of use
10 OUTPUT 717;":SENS1:ROSC:SOUR?"
20 ENTER 717;A$
Equivalent key Displayed on the instrument status bar (at the bottom of the LCD display).
Description
INTernal The external reference signal is not inputted.
EXTernal The external reference signal is inputted.
